1-20t/H Chain Grate Biomass Steam Boiler Temperature 194℃ Feed Uniform
Product Description:
Chain grate biomass steam boiler is designed to meet the chemical industry, light industry, building materials, culture, plastics, rubber processing, paper making, wood processing, clothing, leather and other industries. It is characterized by a wide range of fuel adaptability, including biomass fuels, such as rice husk, straw, wood chips, sawdust, palm husk, coal and other fuels. The boiler adopts horizontal structure, which is convenient for land and sea transportation. The design temperature can reach 184, 194, 204℃, suitable for factories, enterprises to produce steam, hot water.
The steam boiler adopts the advanced grate, the combustion technology is advanced, the structure is reasonable, the load adaptability is strong, the thermal efficiency is high. It is the ideal choice for modern industrial boilers. The chain grate boiler is safe, reliable and efficient, and has won the trust of customers.
Features:
1. The cylinder is composed of arched tube plate and threaded smoke pipe, so that the cylinder changes from quasi-rigid to quasi-elastic structure, cancels the pulling member in the tube plate area and reduces the stress. The smoke pipe in the tube plate is changed from two return trips to one return trips, which solves the problem of tube plate cracks.
2. The threaded smoke pipe is used to strengthen heat transfer, improve heat transfer coefficient and thermal efficiency, and adopt reasonable flue gas
The speed is conducive to the disturbance and erosion of smoke in the pipe, and the pipe will not accumulate ash and play the role of self-cleaning.
3. Compact structure, compared with the same type of boiler, small size, saving boiler room infrastructure investment
Technical Parameters:
| Parameter | Value |
|---|---|
| Application | Chemical Industry, Light Industry, Building Materials, Culture, Plastic Foam, Rubber Processing, Paper Making, Wood Processing, Clothing And Leather |
| Mode of transport | Land And Sea Transport |
| Design Temperature | 184,194,204℃ |
| Type | Chain Grate Biomass Steam Boiler |
| Design Efficiency | ≥83% |
| Warranty Period | 12 Months |
| Structural form | Horizontal |
| Fuel | Biomass Fuels, Such As Rice Husks, Straw, Wood Chips, Sawdust, Palm Husks, Coal, Etc. |
| Design Pressure | 1.0,1.25,1.6Mpa |
| Control System | PLC Intelligent Control System |
Applications:
TAIGUO chain row biomass steam boiler is a horizontal biomass steam boiler, with high efficiency, short installation time, low cost, low energy consumption. Passed CEEACSGSISO19001ISO24001ISO45001 certification. It is ideal for industrial and commercial use, providing efficient, safe and reliable steam boilers. Delivery time according to the agreed delivery time, the supply capacity of 100 sets. Design efficiency ≥83%. The fuel can be biomass fuel, such as rice husk, straw, wood chips, sawdust, palm husk, coal, etc. The design temperature is 184,194,204℃, and the control system is PLC intelligent control system.
Support and Services:
- 24/7 online customer service.
- Free technical consultation and solution design.
- On-site installation and commissioning.
- Regular maintenance and after-sales services.
- Spare parts supply and quick response.
FAQ:
Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
