Steam Generator Boiler Small Vertical Steam Boilers Generator Machine
Price:
US $5500.00
MOQ:
1
Delivery Time:
22 working days
Brand:
TAIGUO
Product Description
Product introduction:
The TAIGUO vertical steam boiler operating system is fully automatic touch screen control, and all operating conditions can be clearly seen on the LCD screen. You can observe the working status, water level status, steam pressure high and low status, pump operation status, fault alarm status, etc. on the display screen, so that you can always grasp the operating status of the equipment and use it with peace of mind.
The use of high-quality components: All pipelines and instruments are connected with seamless steel pipes or pressure resistant copper pipes, and the electrical appliances are well-known in China, ensuring safe and reliable use.
Product advantages:
1. Environmental protection
Widely applicable and in compliance with environmental requirements;
2. Economy
By adopting the latest energy-saving and environmental protection technologies, it can save about 3-8% of costs per month. Using efficient insulation materials, the heat loss is very low, saving fuel costs;
3. Safety
Equipped with water shortage, overpressure, and overheating protection functions, safe and reliable;
4. Practicality
The device has a simple structure, a small footprint, convenient installation and maintenance, and a long service life.
Technical parameter:
|
Model |
Rated Capacity (t/h) |
Rated Pressure (Mpa) |
Rated Temperature (C) |
Maximum transport weight of boiler(t) |
Maximum transport size of boiler( mm) |
Fuel Consumption | ||
|
diesel oil (Kg/h) |
Natural gas (m³/h) |
LPG (kg/h) |
||||||
| LHS0.05 | 0.05 |
0.4 |
151 |
0.37 | 700× 650×1700 | 8.2 | 10.2 | 6.45 |
| LHS0.1 | 0.1 | 0.59 | 800×750 ×2000 | 11.3 | 13.6 | 13 | ||
| LHS0.2 | 0.2 |
0.4~0.7 |
151~170 |
0.68 | 900× 850×2000 | 15.6 | 18.7 | 19.4 |
| LHS0.3 | 0.3 | 0.83 | 1000×950×2000 | 22.5 | 26.8 | 25.6 | ||
|
LHS0.5 |
0.5 |
1.07 |
1100×1050×2000 |
32.5 |
36.8 |
32 |
||
|
LHS0.7 |
0.7 |
0.4~0.7 |
151~170 |
1.45 |
1200×1150×2200 |
40.6 |
48.5 |
50 |
|
LHS1 |
1 |
1.78 |
1300×1250×2450 |
45.9 |
65.3 |
65 |
||
|
LHS1.5 |
1.5 |
1.9 |
1780×1600×3200 |
78.4 |
102.1 |
97 |
||
|
LHS2 |
2 |
5.2 |
2000×2000×4000 |
91.8 |
130.6 |
130 |
||
|
Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas 2 ,Parameter is for reference only, we can design the boilers based on customers’ needs. |
||||||||
