Water Tube Steam Boiler With Flue Gas Condensation Recovery For Benefit

Product Introduction:

The water-cooled wall and convection flue of the SZS oil-gas boiler furnace all adopt membrane wall structure, which has good sealing performance, high heat absorption rate, and effectively reduces the use and maintenance workload of refractory bricks. This boiler uses high thermal resistance material as the insulation layer. It has good thermal insulation performance. An energy-saving condenser is arranged at the tail. It can effectively reduce the exhaust temperature and the boiler has high thermal efficiency. The low-nitrogen fully automatic burner reduces the harmful pollutants in the flue gas and operates without noise. It also has ignition program control and flameout protection functions, which are safe to operate.

Product Advantages:

1. The double-drum "D" type layout is adopted, which has a compact structure, small footprint and good flame filling.
2. The furnace adopts a water-cooled wall structure, and the boiler as a whole adopts a fully enclosed welded structure with an airtight inner guard plate, and the furnace wall has good sealing.
3. The boiler has a large heating surface area, and is designed with a large enough steam-water space, and the boiler parameters are stable.
4. A flue gas condensation recovery device is arranged at the tail, which can effectively control the exhaust gas temperature and boiler heat.
5. High thermal resistance material is used as the insulation layer, and the thermal insulation performance is good. The outer layer of the boiler adopts a pressed guard plate, which looks beautiful and beautiful.

Technical Parameters:

Model ltem		SZS4	SZS6	SZS10	SZS15	SZ20	SZ25	SZS30	SZS35	SZS40
Rated evaporation (t/h)		4	6	10	15	20	25	30	35	40
Rated working pressure (Mpa)		1.25/ 1.6/2.5
Rate steam temperature (℃)		194/204/226
Feed water temperature (℃)		20	20	104/20	104/20	104/20	104/20	104/20	104/20	104/20
heating area(m)	Body	90.22	125.6	205.56	216.84	271.5	285.24	392.34	457.7	523.12
	Economizer	35.8	63.4	132.2	283.6	411.2	504.8	471.2	549.7	628.2
	Condenser	25.4	41.5	62.8	101.1	134.7	168.3	252.4	294.7	336.8
Available Fuel		natural gas ,biogas ,coke gas ,light oil ,methanol ,biodiesel etc ,heavy oil
Fuel consumption	Natural gas (Nm3/h)	288	432	720	1080	1440	1800	2160	2525	2881
	Light oil (kg/h)	244	372	620	930	1240	1550	1860	2079	2373
Thermal efficiency (%)		＞98
Weight biggest part of Transportation (t)		25	32	40	45	50.6	60	68.2	77	85.5
Overall dimension boiler assembied L×W×H( m )		5.76*4.1 0*3.70	7.84*3.4 0*3.40	8.00*43. 60*4.70	8.90*3.9 0*4.00	8.90*3.9 0*4.00	10.50*4. 12*4.15	10.50*4. 30*4.23	11.78*4. 40*4.35	12.82*4. 45*4.40

Application:

1. Textile industry
2. Chemical industry
3. Building materials industry
4. Feed industry
5. Brewing industry
6. Food and automobile industry
7. Paper industry
8. Heating industry
9. Hotel

Products:

FAQ:

Q1: How can you get the best price quickly?

1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.

2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.

Q2:Why choose us?

1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.

2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.

Q3: Details of electric control cabinet

Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.

Q4:What is the using life of your boiler?

1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
