Bochen RXG20 150 Ohms 300W Ceramic Tube Wirewound Resistor with Flameproof Construction
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Bochen RXG20 150 Ohms 300W Ceramic Tube Wirewound Resistor
Quick Detail
- Up to 10000W power rating
- Custom terminations/leads available
- Flameproof construction
- Chassis mount, with brackets
- High-temperature coating for optimal heat dissipation
- Excellent power handling and overload capacity
- Includes installation bracket for easy mounting
- Vibration and humidity resistant
Description
RXG20 wirewound resistors are engineered to meet the demanding requirements of modern electronic applications. These resistors are meticulously crafted by winding a high-resistivity metal wire, such as nickel-chromium or other specialized alloys, around a robust insulating core made of ceramic, fiberglass, or another high-temperature material. This construction technique ensures superior heat dissipation and allows the resistors to handle high power loads effectively.
Key Features
- High Precision and Stability: Exceptional precision with tight tolerance levels and low temperature coefficient for stable performance across wide temperature ranges.
- Robust Power Handling: Designed to withstand high power levels and surge currents in power supplies and motor controls.
- Excellent Thermal Management: Wirewound construction enables efficient heat dissipation for extended component lifespan.
- Durability and Reliability: Rugged design withstands harsh operating conditions including high temperatures and mechanical stress.
- Versatile Configurations: Available in various sizes, resistance values, and power ratings to meet specific application requirements.
Specification
| Temperature Coefficient of Resistance | Within ±440ppm/°C |
| Rated Power Free Air | 50W~2500W |
| Operating Temperature Range | -25°C ~ +225°C |
| Resistance Range (Ohms) | See resistance range chart below |
| Tolerance | ±5%, ±10% as per resistance range chart below |
| Type | Resistance Value | Tolerance |
|---|---|---|
| 100W | 1R0 - 2K7 | 5% |
| 120W | 1R0 - 2K7 | 5% |
| 150W | 1R0 - 2K7 | 5% |
| 200W | 1R0 - 2K7 | 5% |
| 300W | 1R0 - 2K7 | 5% |
| 400W | 1R0 - 2K7 | 5% |
| 500W | 1R0 - 2K7 | 5% |
| 600W | 1R0 - 2K7 | 5% |
| 750W | 1R0 - 2K7 | 5% |
| 1000W | 1R0 - 2K7 | 5% |
| 1200W | 1R0 - 2K7 | 5% |
| 1500W | 1R0 - 2K7 | 5% |
| 2000W | 1R0 - 2K7 | 5% |
| 2500W | 1R0 - 2K7 | 5% |
Dimension
Application
RXG20 wirewound resistors are widely used across multiple industries, including:
- Industrial Automation: For controlling and managing power in machinery and equipment
- Automotive: In braking systems, power steering, and engine control units
- Power Supplies: For regulating and stabilizing voltage and current
- Medical Devices: Ensuring precise operation in sensitive medical equipment
- Aerospace and Defense: Providing reliable performance in mission-critical systems
Advantage
- Factory direct supply with no middlemen
- Complete certificates including RoHS, Reach, and quality assurance
- Sufficient production capacity with short delivery time
- Professional after-sales service team
- OEM&ODM services available
