wallbox 40kw dc digital ev charger cee
Price:
$3,700.00/pieces 2-4 pieces
MOQ:
2 pieces
Delivery Time:
Negotiable
Brand:
BENY
Product Description
Products Description
BENY Electric offers a reliable and robust electric fast charger with an attractive design that is easy to own and operate.,with high-quality power electronic components, It is a powerful charging station that can deliver up to 240 kW, with two CCS2 charging outlets.
We are a leading brand in annually producing hundreds of thousands of quality DC protection products and EV charging stations for complete and reliable solar photovoltaic, battery energy storage, and EV charging system. Certified by UL, SAA, CB, CE, TUV, UKCA, ISO, and RoHS, we have the first listed patented DC switch and produce creative solutions like the AFCI solution for rooftop fire protection, dynamic load balancing, and PEN fault detection EV charger.
Product Paramenters
Models | BDC-M20 | BDC-M30 | BDC-M40 | ||
Connectors | CCS2 | CCS2 | CCS2 | ||
Number of plugs | 1 | 1 | 1 | ||
DC output power | 20KW | 30KW | 40KW | ||
AC input voltage | AC380V±15% | AC380V±15% | AC380V±15% | ||
AC input frequency | 45-65Hz | 45-65Hz | 45-65Hz | ||
DC output voltage range | DC50-750V | DC50-1000V | DC50-1000V | ||
DC output current | single connector 50A | single connector 100A | single connector 120A | ||
Cable length | Standard 5m(customizable) | ||||
Efficiency | ≥95% | ||||
Noise emission | ≤65dB | ||||
IP Rating | IP54 | ||||
Warranty | 12 Months | ||||
Enclosure Protection | IK10 | ||||
Standard | IEC/EN 61851, IEC/EN 62196、ISO-15118、DIN 70121 | ||||
Communication Protocol | OCPP 1.6J | ||||
Status indication | 9.1 inch LCD screen/LED light | ||||
Connectivity Authorization | RFID/NFC, App, VIN | ||||
Network connection | 4G/Ethernet | ||||
Electrical protections | Under voltage、Over voltage、Short circuit、Over current、Leakage Protection、Over temperature、Emergency stop 、Surge protection、Insulation detection | ||||
Cooling method | Air cooling | ||||
Operating temperature | -25℃〜+55℃ | ||||
Storage temperature | -40℃〜+80℃ | ||||
Operating humidity | 5%-90% non-condensing | ||||
Maximum installation height | 2000m | ||||
Dimension (W x H x D) | 450 x 760 x 235mm | ||||
