BENY micro inverter 2800W On-Grid Solar System micro inverter solar micro inverters
Price:
$282.99/pieces 100-499 pieces
MOQ:
100 pieces
Delivery Time:
Negotiable
Brand:
BENY
Product Description
Products Description
2800W Solar Micro Inverter
* Connected to four panels
* Rated Power 2940W
* Peak Power 721W
* Peak efficiency 97.5%
* Maximum short circuit current 24A
* Maximum continuous current 20A
* Up to 25 years warranty
Application
Module-level data can be uploaded to the monitoring platform via BENY data transfer units through PLCC/Zigbee.
The products are fully designed, with real materials, the main control chips, power devices, magnetic components and resistance components are all selected from the top international manufacturers, MTBF> 25 years. The structure and heat dissipation design are fully designed to ensure that it can still work at full load when the ambient temperature is 55℃.
Product Paramenters
Model | BYM2800 | |
Input Data(DC) | ||
PV module power range(recommended) | (450-750W)*4,60,66,72 Cell/(300-400W)*8,72 Cell recommended | |
MPPT voltage range | 24V-50V | |
Operating voltage range | 16V-56V | |
Maximum DC input voltage | 60V | |
Maximum short circuit input current | 24A | |
Maximum continuous input current | 20Aⅹ4 | |
Output Data(AC) | ||
Rated output power | 2800VA | |
Maximum output power | 2940VA (Vac≥230，Vmp≥38) | |
Rated voltage/range | 230V/184-253V | |
Rated frequency/range | 50Hz/60Hz(46.5-61)Hz | |
Maximum continuous output current | 12.17A | |
Maximum harmonic distortion | <3% | |
Power factor | +/-0.95 | |
Maximum connection number in one string | 2 units （30A circuit breaker, 9AWG cable） | |
Efficiency | ||
Peak efficiency | 97.50% | |
European efficiency | 97.00% | |
MPPT efficiency | >99.8% | |
Night power consumption | <100mW | |
Other parameters | ||
Communication method | PLCC/Zigbee dual module | |
Safety protection class | Class I | |
Enclosure rating | IP67 | |
Operating temperature | -40℃ to +70℃ | |
Storage temperature | -40℃ to +85℃ | |
Relative humidity | 0-98% | |
Transformer design | High frequency transformer, Galvanically isolated | |
Overvoltage class | OVC III (AC main circuit)，OVC II (PV) | |
Warranty period | 10 years / 25 years(Optional) | |
Safety regulations | VDE-AR-N 4105, IEC/EN61000,IEC/EN62109-1/2,EN50549-1/2019, TOR2019 C10/11:2019, UTE C15-712-1:2013, VFR2019 | |
