DC+AC COMBINER BOX IP65 with DC AC protection for pv combiner box solar panel
DC+AC Box for Solar PV System
IP65 DC + AC box includes the DC and AC protection for solar PV system.
Including over-voltage protection and isolating at solar DC side.
Equips AC breaker ( RCCB or RCBO for options ) and AC surge arrester at AC side.
An isolating plastic plate between DC components and AC components ensure safety operating.
DC Switch
*UL508i approval and design, IEC60947
*Patented DC arc extinguish chamber
*Magnetic Steels inside ensure rapid and safe DC extinguishing
DC SPD
*New IEC 61643, UL1449
*Designed for solar PV protection
*Higher capacity In 20KA ( IEC, UL )
*Response time <25ns
![]()
-
DC+AC BOX FOR SOLAR PV SYSTEM
IP66 DC + AC box includes the DC and AC protection for solar PV system.
Over-voltage and over-load protection for solar DC side.
AC breaker and AC surge arrester at AC side.
An isolating plastic plate between DC components and AC components ensure safety operating.
-
Specification
Model Number
BHS-1/1(DC+AC)
DC Input
1 string
DC Output
1 string
Max Voltage
600V
1000V
Max Current Output
50A
AC RCCB (RCBO for option)
Type A 40A 300mA
AC Breaker 1
For AC load protection
AC Breaker 2
For AC SPD protection
Enclosure
Material
Polycarbonate
Degree of Protection
IP65
Impacts
IK10
Dimensions (W*H*D)
13 modules: 292*220*120mm
DC Input / Output
MC4 connectors
AC Cable Gland
PG 13.5
Environment
Operating temperature
-25℃ - +60℃
Q:Can I get a sample before I place an order ?
A:Yes,of course and sample fee will be charged but it is refundable if you place order afterwards.
Q:When will I receive my order normally?
A:Normally , It takes 1 week from 1-100 pieces, 2 weeks from 100- 500 pieces, 3-4 weeks if it ups to 500 pieces..
Q:What is your payment methods ?
A:We can accept 100% TT via Alibaba .
Q:What is your shipping methods?
A:Normally we ship goods by express ,by air or sea.
Q:How long the warranty lasts for?
A:Our policy allows to exchange within 5 years.
