24 Strings PV Array Solar Combiner Box TUV IP65
Tips of the Quality Solar Combiner Box:
1. Enclosure: A direct impact on the life of the combiner.
- Most combiners box are installed outdoor, IP65 IP66 degree is important.
- UV resistance and good flame retardant for PC plastic enclosure.
- The larger enclosure for better cooling of internal components.
2. True DC components for solar PV.
- As TOP 1 solar DC components manufacturer in China, the solar combiner box is equiped with TRUE DC disconnect switch, 1000V DC surge arrester which is used in SolarEdge Inverter too and Finger safe touch 1000V DC fuse holder.
- The fuse should be TOP brands from LITTEL or Bussmann.
PV array solar combiner box is equipped with DC-PV2 disconnect switch, finger safe touch DC fuse holder and type 2 DC surge arrester.
All the best DC components are pre-assembled in a durable enclosure.
These reliable PV components bring maximum protection.
Keep the solar PV system safe and in good operation condition, longer the system working life.
Custom design and optional
With or without fuse holder
Door clutch operation solution
We offer customize solutions for your projects.
Highlight:
* 1000V
* 24 strings input
* 1 strings output
Enclosure:
* IP65 protect degree for outdoor and indoor
* Powder coated metal
DC Switch:
* 1200V 4P 400A
* DC-PV2 category Highly reliable
* IEC 60947.3
Type 2 DC Surge Arrester: BUD-40/3
* Over-voltage protection
* 1000V 40KA
* IEC61643 / EN50539
* Recommend by top inverter brands
DC Fuse Holder: BR-30
* Over-current protection
* LED indicator
* Finger safe touch
* 10x38mm LITTEL 1000V 15A
| Model | BHS-24/1 |
| Certificate | TUV |
| Standard | IEC62109 IEC61439 |
| Warranty | 5 Years for any quality problems |
| Voltage | 1000V |
| DC Switch Mechanical Cycle | 10000 |
| DC Switch Electrical Cycle | 600 |
| Protection Degree | IP65 |
Tim Wu
Email: benyi(at)zjbeny.com
Skype: timwu9111
Web: www.zjbenydc.com
Find the true DC components manufacturer.
You find the reliable supplier of reliable solar combiner box.
You have the string level protection for your projects.
ZJBENY is located in Yueqing City, the switch city of China.
We are specialized in solar DC components for 30 years.
The first DC switch manufacturer listed by AS 60947.3:2018 and UL508i in China.
Top 1 DC components and DC string box supplier in China.
