Solar Dc Isolator Switches 6p 1000v/30a For Photovoltaic Disconnector Isolation Switch
* BENY BYSS Series DC disconnect switch is used in 1-200KW solar inverter, 2Pfor 1 load up to 1200V 50A or 1600V 16A. low temperature rising, long worklife andshort arcing time. For Multiple independent MPPTs.
| Electrical characteristics | |
| Type | BYSS.1-50/T-6 |
| Function | Isolator, Control |
| Pole | 6P |
| Rated conditional short-circuit current | 1.5 KA |
| Rated impulsed withstand voltage | 8.0kv |
| Suitability for isolation | Yes |
| IP rating panel | IP66 |
| Mounting | Panel mounting |
| Number of cycles of operation(with current) | 300 |
| Number of cycles of operation(without current) | 10000 |
| Ambient temperature allowed between | -40°C~+85°C |
| Storage temperature allowed between | -40°C~+85°C |
Find the true DC components manufacturer.
You find the reliable supplier of reliable solar combiner box.
You have the string level protection for your projects.
BENY is top 1 DC switch brand in solar PV industry.
The first DC switch listed by UL508i in China.The first DC isolator in full range complies with AS60947.3:2018DCPV2.
Recommend to solar PY installers by top inverter companiesworldwide and Clean Energy Council Australia.
we are developing true DC components at 1000V 1500v,supplyingDC string level safety to solar PV industry.
Q:Can I get a sample before I place an order ?
A:Yes,of course and sample fee will be charged but it is refundable if you place order afterwards.
Q:When will I receive my order normally?
A:Normally , It takes 1 week from 1-100 pieces, 2 weeks from 100- 500 pieces, 3-4 weeks if it ups to 500 pieces..
Q:What is your payment methods ?
A:We can accept 100% TT via Alibaba .
Q:What is your shipping methods?
A:Normally we ship goods by express ,by air or sea.
Q:How long the warranty lasts for?
A:Our policy allows to exchange within 5 years.
