China 3GPP R15 5G Portable Wifi Router GNSS GPS / GLONASS / Galileo / BDS / QZSS for sale

3GPP R15 5G Portable Wifi Router GNSS GPS / GLONASS / Galileo / BDS / QZSS

Name: 3GPP R15 5G Portable Wifi Router GNSS GPS / GLONASS / Galileo / BDS / QZSS
Brand: Hunan Sanyi Technolody limited

Price Negotiable

Price: US$39-US$45/PC

MOQ: 1

Delivery Time: 5-8 working days

Brand: SY

Product Description

MT7975DN+MT7915DAN 5G Router: 3GPP R15, GNSS GPS/GLONASS/Galileo/BDS/QZSS

CPU/Memory

CPU: MT7621A, MT7975DN+MT7915DAN
RAM: 128M

ROM: 16M

5G/4G
Platform: UniSoC

Standard: 3GPP R15

Compatibility: 5G / 4G / 3G

5G architecture: NSA / SA

Frequency(optional):
CN - WCDMA/HSPA+: Band 1/2/5/8, LTE FDD: Band 1/2/3/5/7/8, LTE TDD: Band 34/38/39/40/41, NR: n1/n281/n41/n78/n79

AE - WCDMA: Band 1/2/5/8, FDD-LTE: Band 1/2/3/5/7/8, TDD-LTE: Band 34/39/40/41,

FDD - NR: n1/28, TDD-NR: n41/77/78/79, GNSS: GPS/GLONASS/Galileo/BDS/QZSS

EAU6 - 5G Sub-6: n1/3/5/7/8/20/28/38/40/41/75/76/77/78, LTE FDD: B1/3/5/7/8/20/28/32

LTE TDD: B38/40/41/42/43, WCDMA: B1/5/8, 5G NR DL 4*4 MIMO: n1/3/5/7/20/28/38/40/41/75/76/77/78 UL 2*2MIMO: n41/77/78, LTE : DL 4*4 MIMO: B1/3/5/7/20/28/32/38/40/41/42/43

5G rate: 2.2Gbps / 766Mbps Max(Region dependent)

4G rate: 487Mbps / 150Mbps Max(Region dependent)


WLAN
Standard: WiFi 6, compatible with IEEE 802.11 ac/n/b/g/a

Frequency: 2.4 Ghz / 5.8G
Radio mode: MiMo dual 2x2
Transmit Power: 18dBm(5.8G), 18dBm(2.4G)
Data rate: 1201Mbps(5.8G)+574Mbps(2.4G)
Concurrent Clients: 120
Sensitivity:
11ax: -60dBm@10% PER, 11ac: -62dBm@10% PER, 11n: -68dBm@10% PER,
11g: -70dBm@10% PER, 11a: -68dBm@10% PER, 11b: -88dBm@8% PER
Antenna

5G/4G: Integrated 5G/4G main/diversity antenna

WiFi: Integrated 2 x 2.4 Ghz 5dBi omni, Integrated 2 x 5.8 Ghz 5dBi omni


Interfaces

Wire: 3 x 10/100/1000M ETH port RJ45

Card slot: 1 x Nano SIM

LED: 1 x PWR, 1 x WPS, 1 x Internet, 1 x WiFi

Other: 1 x Reset Button, 1 x WPS button, 1 x PWR button


Software
Operating system: Customized Linux or Openwrt, Feature customizing
Operating mode: Router, Wireless station, Wireless repeater, 5G/4G mode
Internet method: 5G/4G, WAN(Static IP, DHCP client, PPPoE client)
Services: DHCP Server, DHCP Relay, DDNS
Network techniques: Port forwarding, DMZ, UPnP, VPN(L2TP/PPTP, IPSec under OpenWrt, Static routing
Security: IP filtering, MAC filtering, URLfiltering, Port-scanning / SYN flooding attack defense
QoS: Speed limitting based on IP
5G/4G: IMEI code modifying, Frequency locking, Multi-SIM card, Data usage management, Manual APN,.etc.
Other: Internet status detecting, Network switching


Physical

Dimension: 215 mm x 98 mm x 98 mm

Weight: 825g

Power

Power supply: 12V/1.5A DC

Power source: 100 – 240V AC, 50/60Hz

Power consumption (max): 16 W


Environmental
Operating temperature: -30°C ~ +55°C

Humidity: 0 ~ 90 % (non-condensing)



Package contains
Router: 112V 1.5A DC: 1
Other: 1 x User Manual, 1 x Warranty card



			Frequency band



			CN

			AE

			EAU6



			WCDMA/HSPA+: Band 1/2/5/8
LTE FDD: Band 1/2/3/5/7/8
LTE TDD: Band 34/ 38/39/40/41
NR: n1/n281/n41/n78/n79

			WCDMA: Band 1/2/5/8
FDD-LTE: Band 1/2/3/5/7/8
TDD-LTE: Band 34/39/40/41
FDD-NR: n1/28, TDD-NR:
n41/77/78/79
GNSS: GPS/GLONASS/Galileo/BDS/
QZSS

			5G Sub-6: n1/3/5/7/8/20/28/38/40/41/
75/76/77/78
LTE FDD: B1/3/5/7/8/20/28/32
LTE TDD: B38/40/41/42/43
WCDMA: B1/5/8
5G NR DL 4*4 MIMO: n1/3/5/7/20/28
/38/40/41/75/76/77/78 UL 2*2MIMO:
n41/77/78
LTE : DL 4*4 MIMO: B1/3/5/7/20/28/32/
38/40/41/42/43





Company Profile

Hunan Sanyi Technology Co., Ltd. located at Changsha, China. Professional in R&D and producing network devices, specially for processing OEM/ODM. Products include openWRT WiFi router, 4G/5G router, Mesh Router, WiFi 6 Router, Industrial&Enterprise Router, Vehicles Router, AP, Outdoor CPE and LTE CPE. Sayi is also a Wi-Fi coverage service provider, provides the solution for hotel, school, hospital, enterprise, airport and vehicle field. We have built a long term cooperation with Mediatek, Broadcom and Qualcomm, capably offering good quality products and fast after-sale service to our clients. Our main customers are China Mobile, Vivacom in Bulgaria, Sprint, T-Mobile, AT&T in USA and Smart in Philippine.

FAQ

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. How to proceed an order?

A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Then we arrange the production.

Q3. How do you ship the goods and how long does it take to arrive?

A: We usually ship by Ali-Logistics, DHL, UPS, Fedex, TNT, EMS, SF Express or your designated forwarder. It usually takes 3-7 days to arrive. Airline and sea shipping also optional.

Q4. What is your payment term?

We have Ali- pay, T/T, Visa,Western Union payment terms options, you can choose the one which is convenient or effective for you!

Q5. Can you customized logo and packaging?

A: Yes, OEM/ODM are acceptable. Our design team will help you design as your requirement.
