Airbag Launching Ship Rubber Inflatable Lifting Marine Airbags For Boat Vessel
Airbag Launching Ship Rubber Inflatable Lifting Marine Airbags for Boat Vessel
Description
Airbag launching systems are designed for maximum portability and adaptability. Their lightweight construction and compact design make them easy to transport and set up at diverse locations. Whether in a remote coastal area or a bustling urban shipyard, airbag launching technology can accommodate varying operational needs.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Model Number | HM-ALS490 |
| Material | Industrial-Grade Natural Rubber |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Airbag Launching Ship |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
Precision Engineering
Designed for optimal performance and safety.
Lightweight and Compact
Easy to handle and store when not in use.
Low Noise Operation
Produces minimal noise during the launching process.
Industry Standard Compliance
Certified for use in maritime operations globally.
Applications
Advantages
Emergency Manufacturing Capabilities
Quick response to urgent customer needs.
Continuous Improvement
Regular updates to designs and manufacturing techniques.
Expert Consultation Services
Professional advice on product selection and use.
Flexible Order Quantities
Accommodating both bulk and small-scale orders.
FAQ
1. Are airbags suitable for large vessels?
Yes, they can launch vessels of various sizes, including large cargo ships.
2. Can airbags be used in remote locations?
Yes, minimal infrastructure is required for airbag launching.
3. What types of projects are ideal for airbag launching?
New ship launches, repairs, salvage operations, and ship recycling.
4. Can airbags be used for emergency operations?
Yes, they are ideal for quick deployment in emergencies.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
