Customizatied Boat Airbag Launching Ship And Lift Floating Marine Rubber Airbag
Customizatied Boat Airbag Launching Ship and Lift Floating Marine Rubber Airbag
Description
Airbag launching technology provides a revolutionary solution for launching ships, eliminating the need for traditional slipways or cranes. This method uses durable rubber airbags to lift and launch vessels into the water efficiently. It is highly cost-effective, requiring minimal infrastructure and manpower, making it an ideal choice for small and medium-sized shipyards. The technology is versatile and can accommodate various vessel types, from fishing boats to cargo ships, while ensuring safety and precision during the launch process.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Model Number | HM-ALS1258 |
| Material | Industrial-Grade Natural Rubber |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Airbag Launching Ship |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
Environmentally Friendly
Minimal environmental impact due to reduced water and energy consumption.
Safe Operation
Offers controlled and smooth launches, minimizing risks.
Space Saving
Requires significantly less space than traditional slipways or cranes.
Durable Materials
Made from high-strength rubber for long-lasting performance.
Applications
● Coastal shipyards
Advantages
Skilled Workforce
Experienced engineers and technicians ensure precision and reliability.
Customizable Solutions
Tailored airbags for various vessel sizes and shipyard needs.
Diverse Product Range
Airbags available in multiple sizes, diameters, and capacities.
Durable Materials
Use of high strength rubber for longevity and performance.
FAQ
1. Is airbag launching a proven technology?
Yes, it is widely used in shipyards around the world with a high success rate.
2. What materials are the airbags made of?
High strength, wear-resistant rubber and synthetic fabrics.
3. What sizes are available for airbags?
Airbags come in various diameters and lengths to suit different vessels.
4. What is the lifting capacity of an airbag?
It varies by size and design, but they can handle several tons per airbag.
