Description
Airbag launching is an eco friendly alternative to traditional methods. It minimizes the need for heavy infrastructure, reduces water and energy consumption, and has a lower impact on surrounding ecosystems. With its sustainable approach, this technology supports environmentally conscious shipbuilding practices, helping shipyards meet modern environmental standards without compromising efficiency or quality.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Model Number | HM-ALS136 |
| Material | Industrial-Grade Natural Rubber |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Airbag Launching Ship |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
Energy Efficient
Requires less energy compared to traditional launching methods.
Low Maintenance
Designed for durability and minimal upkeep.
Reduced Risk of Ship Damage
Provides cushioning to protect the vessel during launch.
No Heavy Infrastructure Needed
Eliminates the need for cranes, rails, or other expensive equipment.
Applications
● Rescue vessel launching
Advantages
Environmentally Friendly Practices
Commitment to sustainable manufacturing.
Strong Lifting Capacity
Airbags designed for heavy duty applications.
ISO Certified Products
Compliance with international standards and certifications.
Innovative Design
Advanced engineering for optimal safety and performance.
FAQ
1. Can airbags be used in rough weather?
Yes, but calm conditions are preferred for optimal safety.
2. What maintenance do airbags require?
Regular cleaning, inspection for wear, and proper storage.
3. Are airbags resistant to damage?
They are built to withstand abrasion, chemicals, and environmental conditions.
4. Can airbags be used for docking operations?
Yes, they are suitable for both launching and docking.
