2.5mm Double Stitched Seams Boat Lift Helper For Added Strength And Durability
Boat Lift Helper Double Stitched Seams For Added Strength And Durability
Description
One of the standout features of the Boat Lift Helper is its user-friendly design. The parachute-style lift bag is simple to deploy and requires minimal setup, making it accessible even for those with limited experience in underwater lifting operations. The intuitive design includes clear markings and instructions, ensuring that users can quickly and efficiently prepare the lift bag for use. Additionally, the Boat Lift Helper is lightweight and easy to transport, allowing for hassle-free deployment in various locations. This ease of use makes it a practical solution for a wide range of underwater lifting tasks.
Specifications
| Product Name | Boat Lift Helper |
| Raw Material | Top Notch PVC Coating Fabric |
| Type | Parachute |
| Size | 500kg, 1000kg, 5000kg 10000kg, etc |
| Thickness | 0.4-1.2mm, or as request |
| Color | Yellow, Blue, Black, etc |
| Density | 0.33-0.9g/cm3 |
| Safety Factor | 7:1 |
| Accessories | Valve, Inflatable Tube, Repair Material |
| OEM | Welcome |
| Warranty | 3 Years |
|
Tolerances |
+/- 0.03 on densities +/- 0.2 mm on thickness +/- 0 to +3mm on width +/- 0 to +3mm on length |
| Model | Lifting Capacity | Dimensions | Appr. Weight | |
| Parachute | [kg] | [lbs] | [mm] | [kg] |
| HM-P01 | 200 | 441 | 800 | 5 |
| HM-P02 | 500 | 1,103 | 1,000 | 8 |
| HM-P03 | 1,000 | 2,205 | 1,300 | 11 |
| HM-P04 | 2,000 | 4,410 | 1,600 | 20 |
| HM-P05 | 4,000 | 8,820 | 2,000 | 50 |
| HM-P06 | 6,000 | 13,230 | 2,300 | 66 |
| HM-P07 | 8,000 | 17,640 | 2,500 | 75 |
| HM-P08 | 10,000 | 22,050 | 2,700 | 80 |
| HM-P09 | 15,000 | 33,075 | 3,100 | 110 |
| HM-P10 | 20,000 | 44,100 | 3,400 | 130 |
| HM-P11 | 30,000 | 66,150 | 3,900 | 170 |
| HM-P12 | 50,000 | 110,250 | 4,600 | 220 |
| HM-P13 | 70,000 | 154,350 | 5,200 | 310 |
| HM-P14 | 100,000 | 220,500 | 5,800 | 450 |
| HM-P15 | 150,000 | 330,750 | 6,600 | 660 |
| HM-P16 | 200,000 | 441,000 | 7,300 | 900 |
| *Note: Other sizes can be customized according to the requirements. | ||||
Features
Controlled Ascent
Prevents sudden or uncontrolled rises, ensuring safety during lifting.
Compact Storage
Takes up minimal space when not in use, ideal for boats or dive gear storage.
Cost Effective Solution
Provides a high-performance lifting option at a competitive price.
Long Lifespan
Built to last, reducing the need for frequent replacements.
Applications
● Raising shipwrecks
● Supporting bridge and pier repairs
● Lifting heavy machinery underwater
● Retrieving lost cargo from shipwrecks
Advantages
Long Lifespan
Products engineered to withstand repeated use, reducing the need for frequent replacements.
Low Maintenance Requirements
Easy-to-clean and repair designs to minimize downtime.
Proven Track Record
Trusted by professionals in salvage, diving, and marine industries worldwide.
Innovative Designs
Continuous improvement and innovation to stay ahead of industry trends.
FAQ
1. What is the maximum weight it can lift?
The lift capacity varies by model, ranging from small loads to several tons.
2. Is the Boat Lift Helper safe to use?
Yes, it includes safety features like pressure relief valves to prevent over-inflation and ensure controlled lifts.
3. Can it handle rough underwater conditions?
Yes, it’s designed to perform reliably in strong currents, deep water, and low visibility.
4. Does it require special training to operate?
Basic training is recommended, but its intuitive design makes it easy to learn.
