Air Filled Rubber Airbag Ship Launching Marine Airbag For Boat Big Vessel
Air Filled Rubber Airbag Ship Launching Marine Airbag for Boat Big Vessel
Description
Underwater lifting requires tools that can handle extreme pressure and harsh conditions. Rubber Airbags designed for this purpose provide high buoyancy and precise inflation control, ensuring stable and safe lifting of submerged objects like shipwrecks or pipelines.
Their compact design allows them to be deployed in confined spaces, while their reinforced rubber layers resist damage from saltwater, abrasion, and strong currents. Rubber Airbags are essential for underwater construction, salvage, and maintenance, offering efficiency and reliability in demanding marine operations.
Specifications
| Item | Description |
| Place of Origin | China |
| Brand Name | Hongruntong Marine |
| Material | NBR |
| Diameter | 0.5m-3.0m, or as Request |
| Length | 1.0m-28.0m, or as Request |
| Working Pressure | 0.05-0.25 mpa |
| Technics | High pressure, overall winding, explosion-proof |
| Use | ship launching and docking |
| Thickness | 5-13 ply |
| Standard | Conducted by ISO14409 and GB/T1590-2006 system. |
| Accessories | Q355/SS304/SS316, Pressure Gauge, Tee, Plug, Switch, Inflation Tube |
| Packaging | Inner-Plastic Bag; Outer-Standard Wooden Pallets. |
| Keywords | Rubber Airbag |
| Certificates | ABS, BV, KR, LR, GL, NK, RINA, DNV, RMRS |
| MOQ | 1 |
| OEM | Welcome |
| Diameter |
Working Pressure |
Working Height |
Bearing Capacity | |
| KN/m | Ton/m | |||
| D=1.0m | 0.14Mpa | 0.6m | 87.96 | 8.98 |
| 0.5m | 109.96 | 11.22 | ||
| 0.4m | 131.95 | 13.46 | ||
| D=1.2m | 0.12Mpa | 0.7m | 94.25 | 9.62 |
| 0.6m | 113.10 | 11.54 | ||
| 0.5m | 131.95 | 13.46 | ||
| 0.4m | 150.80 | 15.39 | ||
| D=1.5m | 0.10Mpa | 0.9m | 94.25 | 9.62 |
| 0.8m | 109.96 | 11.22 | ||
| 0.7m | 125.66 | 12.82 | ||
| 0.6m | 141.37 | 14.43 | ||
| 0.5m | 157.08 | 16.03 | ||
| D=1.8m | 0.09Mpa | 1.1m | 98.96 | 10.10 |
| 1.0m | 113.10 | 11.54 | ||
| 0.9m | 127.33 | 12.98 | ||
| 0.8m | 141.37 | 14.43 | ||
| 0.7m | 155.51 | 15.87 | ||
| 0.6m | 169.65 | 17.31 | ||
| D=2.0m | 0.08Mpa | 1.2m | 100.53 | 10.26 |
| 1.1m | 113.10 | 11.54 | ||
| 1.0m | 125.66 | 12.82 | ||
| 0.9m | 138.23 | 14.11 | ||
| 0.8m | 150.80 | 15.39 | ||
| 0.7m | 163.36 | 16.67 | ||
| 0.6m | 175.93 | 17.95 | ||
| * Other size can be produced follow client's requirements. | ||||
Features
Lightweight
When deflated, these airbags are lightweight, enabling easy handling and transportation.
Flexible in Use
Suitable for both small-scale and large-scale marine operations, offering flexibility.
Enhanced Safety
Designed to ensure stability and reduce the risk of accidents during heavy lifting or ship launching.
Stabilizing Features
Provides stabilization during the transportation and movement of heavy marine structures.
Applications
● Marine decommissioning projects
● Installation of submerged pontoons
● Marine seismic survey operations
● Subsea vehicle deployment
Advantages
Flexible Payment Terms
Offering flexible payment options to accommodate client needs.
Robust Delivery Network
Reliable logistics and shipping partners for fast and secure delivery.
Customizable Accessories
Availability of additional accessories such as inflation equipment and repair kits.
Affordable Shipping Costs
Cost-effective shipping solutions to reduce overall project costs.
FAQ
1. What is the maximum inflation pressure for a Rubber Airbag?
Typically, the maximum pressure is around 0.2 MPa (2 bar), but it varies by model.
2. Can Rubber Airbags be used for underwater lifting?
Yes, Rubber Airbags are widely used for lifting submerged objects like sunken vessels, pipelines, or construction materials.
3. Are Rubber Airbags resistant to UV rays?
Yes, most Rubber Airbags are treated with UV-resistant coatings to prevent degradation from sunlight exposure.
4. How do I maintain a Rubber Airbag?
Clean the airbag with fresh water after use, inspect for damage, store it in a cool, dry place, and avoid exposure to sharp objects.
