ISUZU ELF 190hp 4x4 AWD 18 Meters Aerial Work Platform Truck
Price:
USD 42200- USD 45200/ UNIT
MOQ:
1 UNIT
Delivery Time:
45-60 work days
Brand:
ISUZU
Product Description
ISUZU ELF 190hp 4x4 AWD 18 Meters Aerial Work Platform Truck
Product Description
1suzu Scissor Lift Platform Truck, also called Man Lift Working Truck, Aerial Man Lift Truck, Scissor Lift Working Truck, Scissor Lift Platform Special Truck.
The Scissor Lift Platform Truck has 2-3 folding arms and provides temporary access for people or equipment to inaccessible height areas. The arm shaft is compact,flexible and large operating range. Four hydraulic supporting legs are used for the platform and have large span and good stability, which can be stretch out and draw back both independent.
The aerial bucket platform working height can reach to 12 to 42meters
| Chassis Specification | ||||
| Truck model | CLW5118JGKIS18 | |||
| Cab | ISUZU 700P single row of seats cab, with air-conditional andUSB connector radio. | |||
| Driving Type | 4*2 Left hand driving | |||
| Max Speed (km/h) | 95 | |||
| Overall dimension (mm) | Appro. 7400*1980*3200 | |||
| GVW (kg) | Appro. 11000 | |||
| Mass in working order( kg) | Appro. 8485 | |||
| Wheelbase (mm) | 3815 | |||
| Tire | 8.25R16 | |||
| Clutch | Single-plate dry diaphragm spring clutch | |||
| Steering | Hydraulic steering with power assistance | |||
| Gear box | MLD 6-speed | |||
| Bridge | Front axle | 4.0T | ||
| Rear axle | 7.0T | |||
| Engine | Model | 4HK1-TCG40 | ||
| Fuel Type | Diesel fuel | |||
| Emission Standard | Europe V | |||
| Type | Water-cooled four-stroke, supercharged inter-cooling | |||
| Exhaust (ml) | 2999 | |||
| Max output power/rotate speed (hp /rpm ) | 190/3400 | |||
| Max torque/rotate speed (N.m/rpm) | 220/1700 | |||
| BrakingSystem | Service Brake | Air brake | ||
| Park Brake | Spring energy | |||
| Electric system | 24v | |||
| Special Function | ||||
| Working height (m) | 18 | |||
| Max working radius (m) | 9 | |||
| Boom type | Two sections folding working boom | |||
| Rated loading in the bucket(kg) | 200 | |||
| Bucket size (mm) | 1300*1000*1000 | |||
| Rotating speed (r/min) | 0-2 | |||
| Rotationangle | 360° | |||
| Supporting leg | four sets hydraulic legs | |||
| Span of supporting legs | Horizontal | 3500mm | ||
| longitudinal | 4000mm | |||
| Boomcontrol mode |
1.Bucket control 2.Manual operation |
|||
| Supporting legs | Four hydraulic supporting legs with manual operation | |||
