HW 600w Single Lamp Single Bar Full Chamber YAG Energy Negative Feedback Welder
Price:
USD / Set
MOQ:
1 Set
Delivery Time:
10 working days
Brand:
HanWei
Product Description
HW 600w Single Lamp Single Bar Full Chamber YAG Energy Negative Feedback Welder
As a flagship product of our company, the HW-YAG-600W adopts a single-lamp-and-rod configuration, while incorporating core components such as imported optical resonators. It boasts a high damage resistance threshold and stable light speed; in terms of technical specifications, it utilizes a self-developed PID adaptive feedback power supply system--this effectively ensures the equipment delivers high conversion efficiency, robust beam stability, excellent penetration capability, and faster welding speed.
When applied to power battery tab welding and seal nail welding, this product achieves a welding efficiency of up to 6 PPM and a qualification rate of 99.5%, making it widely used in the field of power battery welding. Additionally, the equipment is equipped with intelligent monitoring functions for critical parameters, including water flow, water temperature with specific conductivity, and xenon lamps.
Key Features
- Independent R&D, production and sales
- Imported quartz optical lenses and accessories
- More stable light spots and stronger penetration
- Equipped with multiple intelligent monitoring functions
- Single-lamp & single-rod full-cavity water cooling
- Unique optical system design
Technical Specifications
| Model | HW-Y-600 |
|---|---|
| Input Voltage | AC380V 50/60 Hz |
| Wavelength | 1064nm |
| Output Power | 600W |
| Net Weight | 240 Kg |
| Pulse Width | 15 ms |
| Repeat Frequency | 100 Hz |
| Power Stability | 70/100 J |
| Working Mode | Pulse |
| Cooling Mode | Water Cooling |
| Max Pulse Energy | ± 3 % |
| Max Peak Power | 10 Kw |
| Dimension | 1375*628*1150mm |
| Optical Route | 1~4 (Optional) |
| Optical Separate Type | Time / Energy |
| Equipment Power | 20 Kw |
Areas of Applications
New energy battery welding, particularly used in the power battery field.
About Shenzhen Hanwei Laser
Shenzhen Hanwei Laser is committed to making world-class laser welding technology accessible to all system integrators. As a certified national high-tech and "specialized, sophisticated, distinctive, and novel" enterprise, we focus on full-industry-chain R&D, production, and sales of welding-dedicated lasers and related technologies.
Our product portfolio includes:
- Ring-Spot laser welding equipment
- Blue laser welding equipment
- Hybrid welding systems (blue laser + fiber, Diode + fiber, YAG + Diode)
- YAG and Diode laser welding equipment
- Mold repair laser welding equipment
- QCW laser welding equipment
With a team of technical experts specializing in laser welding R&D, we serve industries including new energy batteries, automotive, electronics, medical devices, and more. Our products deliver irreplaceable welding performance across multiple applications.
