Blue Light Hybrid Laser Weld for Sealed Welding of Copper Liquid Cooling Plates
Price:
USD / Set
MOQ:
1 Set
Delivery Time:
10 working days
Brand:
HanWei
Product Description
Blue Light Hybrid Laser Weld for Sealed Welding of Copper Liquid Cooling Plates
Key Features
- Effective Welding for Copper-Based and Reflective Metals.
- Multi-Beam Integration with Adaptive Wobble Function.
- Reduced Energy Requirement for Stable Operation.
- Stable Welding Behavior with Low Spatter Output.
- Improved Energy Coupling for Strong Weld Formation.
Technical Parameters
| Model | HW-B |
|---|---|
| Laser Power | 1000 W |
| Wavelength(um) | 445 nm |
| Head Option | Blue Laser Hybrid |
| Laser Core | 50um / 100um |
| Head Weigh | 4 Kg |
| Focuses | Option |
| Laser Beam | Stationary / Wobble |
| Cooling Method | Water Cooling |
| Machine Size | 1000*450*850mm |
| Power Range | 10-100 |
| Power Instability (%) | ＜ 3 |
| Core Diameter | 200 μm / 0.22 NA |
Applications
The controlled interaction between laser energy and material reduces instability in the molten pool. As a result, spatter generation is significantly minimized, keeping the weld area cleaner and reducing the need for additional finishing work.
High absorption efficiency ensures that more laser energy is effectively transferred into the material. This leads to solid fusion, consistent weld depth, and reliable joint strength, especially in high-performance electrical and conductive applications.
Welding Samples
Shenzhen Hanwei Laser Enterprise
Shenzhen Hanwei Laser Equipment Co., Ltd. provides a full array of laser systems, ranging from benchtop units to portable configurations. These platforms integrate advanced fiber, pulsed or continuous-wave, blue laser, diode laser and hybrid laser solutions, all elaborately developed to meet the personalized needs of its customers.
The company delivers custom-tailored solutions for specific application areas, accompanied by professional support and dependable after-sales service, ensuring users fully utilize the operational performance of their laser equipment. With operational branches and cooperative organizations spanning Europe, North America, Asia and the Middle East, Hanwei Laser has established an extensive global network to serve clients throughout the world.
Laser welding constitutes the core competitive strength of Hanwei Laser. The company is committed to providing pioneering laser welding technologies for international laser system integrators, with the goal of supplying high-end welding solutions for industrial partners. As one of the few enterprises worldwide holding both national high-tech and "specialized, sophisticated, distinctive and innovative" certifications, it focuses on the full industrial chain involving research and development, production and sales of a complete series of welding lasers, laser control systems, laser optical components and laser welding applications.
