2BEC Series Water Ring Vacuum Pump 90kw-500kw

2BEC series water ring vacuum pump and compressor-Water ring vacuum pump

2BE series water ring vacuum pumps and compressors are high-efficiency and energy-saving products developed on the basis of years of scientific research results and production experience, combined with international similar advanced technology, usually used to pump non-solid particles, insoluble in water, non-corrosive gas to create a vacuum and pressure in a closed container. By changing the structural material, it can also be used to pump corrosive gas or corrosive liquid as working fluid. Widely used in papermaking, chemical industry, petrochemical, light industry, pharmaceutical, food, metallurgy, building materials, electrical appliances, coal, metal mines, fertilizers and other industries.

This series of pumps adopts a single-stage single-acting structure, which has the advantages of simple structure, convenient maintenance, reliable operation, high efficiency and energy saving, and can adapt to harsh working conditions such as large displacement and load shock fluctuations. We have carried out a series of optimized designs on key components, such as distribution plates, impellers and pump shafts, to simplify the structure, improve performance and achieve energy saving. Ductile iron or welded impeller is adopted, the blade is formed by stamping at one time, and the profile is reasonable; the hub is all processed, which fundamentally solves the problem of dynamic balance. working conditions.

2BE series pumps are equipped with air-water separators, exhaust ports are provided at multiple positions, and the pump cover is equipped with an exhaust valve maintenance window. The gap between the impeller and the distribution plate is adjusted by the glands at both ends of the positioning bearing. It is easy to install and operate. Easy maintenance.

Our company's vacuum pumps have been strictly inspected and tested by the testing center, and their performance is superior, reliable and durable.
