0.75kw - 185kw Watering Vacuum Pump Used In Pharmaceutical Industry SK Series
SK series water ring vacuum pump and compressor-Water ring vacuum pump
SK series water ring vacuum pumps and compressors are used to suck or compress air and other non-corrosive, water-insoluble, and solid-free gases to form vacuum and pressure in airtight containers. The suction gas is allowed to be mixed with a small amount of liquid . SK water ring vacuum pumps and compressors are widely used in machinery, petroleum, chemical, pharmaceutical, food, sugar industry and electronic fields. Since the gas compression process is isothermal during the working process, it is less likely to cause danger when compressing and pumping explosive gases, so its application is more extensive.
|
model |
Pumping capacity (m/min) |
Vacuum pump ultimate pressure |
Motor Power kw |
pump speed r.p.m |
compressor Mpa |
caliber mm |
water consumption |
||||
|
maximum |
The suction pressure is -0.04MPa |
mmHg |
MPa |
vacuum pump |
compressor |
Enter |
out |
||||
| SK-0.15 | 0.15 | 0.12 | -670 | -0.09 | 0.75 | 1 | 2860 | / | 3-5 | ||
| SK-0.4 | 0.4 | 0.36 | -680 | -0.091 | 1.5 | / | 2860 | / | G1" | G1" | 4-8 |
| SK-0.8 | 0.8 | 0.75 | -680 | -0.091 | 2.2 | / | 2860 | / | G1" | G1" | 5-10 |
| SK-1.5B | 1.5 | 1.35 | -700 | -0.093 | 4 | / | 2860 | / | G1" | G1" | 8-12 |
| SK-1.5 | 1.5 | 1.35 | -700 | -0.093 | 3 | 4 | 1440 | 0-0.1 | 70 | 70 | |
| SK-3 | 3 | 2.8 | -700 | -0.093 | 5.5 | 7.5 | 1440 | 0-0.1 | 70 | 70 | 15-20 |
| SK-6 | 6 | 5.4 | -700 | -0.093 | 11 | 15 | 1440 | 0-0.1 | 80 | 80 | 20-30 |
| SK-9 | 9 | 8.1 | -700 | -0.093 | 15 | 22 | 970 | 0-0.1 | 65 | 65 | 30-40 |
| SK-12 | 12 | 10.8 | -700 | -0.093 | 18.5 | 30 | 970 | 0-0.1 | 80 | 80 | 40-50 |
| SK-15 | 15 | 13.5 | -700 | -0.093 | 30 | 45 | 980 | 0-0.1 | 80 | 80 | 50-60 |
| SK-20 | 20 | 13.5 | -700 | -0.093 | 37 | 55 | 740 | 0-0.1 | 150 | 150 | 60-80 |
| SK-20B | 20 | 18 | -700 | -0.093 | 30 | 45 | 730 | 0-0.1 | 150 | 150 | |
| SK-27 | 27 | 24.5 | -700 | -0.093 | 45 | 55 | |||||
| SK-30 | 30 | 27 | -700 | -0.093 | 55 | 75 | 740 | 0-0.1 | 150 | 150 | 200-100 |
| SK-30B | 30 | 27 | -700 | -0.093 | 45 | 75 | 730 | 0-0.1 | 150 | 150 | |
| SK-42 | 42 | 37.8 | -700 | -0.093 | 75 | 90 | 740 | 0-0.1 | 150 | 150 | 95-130 |
| SK-42B | 42 | 37.8 | -700 | -0.093 | 55 | 75 | 730 | / | 150 | 150 | |
| SK-60 | 60 | 54 | -700 | -0.093 | 90 | 132 | 550 | / | 250 | 250 | 40-180 |
| SK-85 | 85 | 76.5 | -700 | -0.093 | 132 | 160 | 550 | / | 250 | 250 | 180-220 |
| SK-120 | 120 | 108 | -700 | -0.093 | 185 | 220 | 490 | / | 300 | 300 | 220-260 |
