Impact Resistant Colour Coated Coil ID 508mm / 610mm ISO9001 Approved
Impact Resistant Color Steel Coils With ID 508mm/610mm
Product Description:
Color Coated Steel Coil is a kind of steel product manufactured by color steel manufacturing processes. It is a steel coil or steel sheet with PE/SMP/HDP/PVDF coating on the surface. Its yield strength is ≥220MPa, and the elongation is ≥20%, which make it a high quality and durable steel product. The top coating has a thickness of 10-25 microns, and it comes in various RAL colors. Color Coated Steel Coil is widely used in many fields and industries as it is a quality steel product with excellent appearance and durability.
Features:
- Product Name: Color Coated Steel Coil
- Impact Resistance: ≥9J
- Material: Steel
- Surface Hardness: ≥2H
- Color: RAL Color
- Coating: PE/SMP/HDP/PVDF
Technical Parameters:
| Property | Value |
|---|---|
| Surface Treatment | Color Coated |
| Coil ID | 508mm/610mm |
| Coating | PE/SMP/HDP/PVDF |
| Top Coating | 10-25 Microns |
| Yield Strength | ≥220MPa |
| Width | 600-1250mm |
| Tensile Strength | 300-550MPa |
| Thickness | 0.13-0.8mm |
| Surface Hardness | ≥2H |
| Back Coating | 5-12 Microns |
Certificate:
EVANGEL color coated steel coil has a wide range of applications in various industries.
Customization:
Customized Service for Color Coated Steel Coil
Brand Name: EVANGEL
Model Number: 0.13-0.8MM
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 25
Price: 600-1000
Packaging Details: waterproofing paper+plastic film+steel jacket
Delivery Time: 7-30days
Payment Terms: TT LC
Supply Ability: 15000 tons one month
Material: Steel
Surface Hardness: ≥2H
Impact Resistance: ≥9J
Back Coating: 5-12 Microns
Top Coating: 10-25 Microns
Color Coated Steel Coil is a kind of color steel sheet coil, which is made of steel sheet and coated with various organic coatings. It has the characteristics of strong corrosion resistance, bright color, convenient construction, long service life and so on. It is widely used in construction, home appliances, furniture, transportation and other industries. Our Color Coated Steel Coil has the following features:
- High quality steel sheet
- Advanced color coated technology
- Uniform thickness and strength
- Surface hardness ≥ 2H
- Impact resistance ≥ 9J
- Back coating: 5-12 microns
- Top coating: 10-25 microns
We are committed to providing you with high quality products and customized services. If you need Color Coated Steel Coil, please contact us!
Support and Services:
Our technical support and services for Color Coated Steel Coil include:
- Providing detailed information and instructions on installation and maintenance.
- Providing technical advice and customer service.
- Providing technical support for troubleshooting and product use.
- Providing replacement parts and repairs when needed.
- Providing warranty coverage.
