4 Pin LED Waterproof Connector M16 10A PA66 Push Locking Wire To Wire Connectors
4 Pin LED Waterproof Connector , M16 10A PA66 Push Locking Wire To Wire Connectors
Description of Industrial Waterproof Circular Connector
Main Feature
- Push lock quick release system,hassle-free operation.
- Multic-core are available for selection: 2Pin,3Pin,4Pin,5Pin,2+4Pin,7Pin,8Pin.
- Field assembly version:wire to wire / wire to board
- High current rated waterproof connector good choice up to 10A for long time working
- Cable assembly service supported, welcome to custom
- OEM/ODM welcome
| Electrical Parameters | |
| Number of Poles | 4Pin waterproof connector |
| Current Rating | 10A max |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1500VAC @ 60 s. |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Application industries
- Communications Application
- product coding machines
- inventory product coding
- inkjet systems
- Solar System
- industrial inkjet equipment
- Electric power equipment
- Laboratory forensic&pathology equipment
- Communications equipment
- Heavy machinery
Production Dimension
More Technical Details
FAQ
Q1:Can I get a free sample before placing a bulk order?
A1:We offer free samples for standard models, but the shipping cost is at your expense. For customized samples, a small fee will apply and can be deducted from the formal order later.
Q2:Do you support product customization?
A2: Yes, customization is available for specifications, colors and packaging. Please provide your detailed requirements, and we will quote accordingly with a sample confirmation process.
Q3:Can I pay after receiving the goods?
A3: For first - time cooperation, advance payment is required to ensure production smoothness. For long - term trusted clients, flexible payment terms can be discussed after several successful orders.
