3 pin wire to board connector M19 20A 300V waterproof connector for high voltage
M19 3 Pin 300V Waterproof Plug Socket Connector Quick Lock
Main Features
- Item Name : M19 Waterproof Cable Connector
- Specifications : Straight male-female mating, elbow male-female mating, front-mounted wire -to- board, rear-mounted wire -to-board,integrated injection molding
- Coupling way: Self-locking
- Pins number :2-22 pins
- Plug : Assembly type and Injection type available
- Socket: Front Mount, Back Mount, PCB Mount
- Waterproof grade: IP67/ IP68
- Connector type :Assembly lock screw；Assembly welding；Injection molding with cable
- Wire gauge: 1.0-6.0mm² (18AWG-10AWG)
- Wiring range Assembled: 6. 0mm~16mm；Molding 6. 0mm~16.5 mm
- Durability :3000 times
- Applicabletemperature: -40℃~105℃
Quick Description
| Electrical Parameters | |
| Number of Poles | 3 pin |
| Current Rating | 20A max. |
| Voltage Rating | 300VAC max5 |
| Durability Voltage | 1500VAC @ 60 s. |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
| Operation Parameters | |
| Voltage Rating | 600VAC max |
| Current Rating | 15A max |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 2.5mm2 |
Design Sketch
