M25 4 Pin Male Female Connector ROHS Push Locking Wire To Wire Power connector
Waterproof Electrical 500V M25 4 Pin Waterproof Push Lock Connectors
Quick Details of IP67 Waterproof connector
-
Core Specifications and Connection Type: Adopts a 4Pin male-female plug-in structure, focusing on the wire-to-wire connection method, accurately matching the power transmission needs of small and medium-power equipment; the interface specification is M25 standard, with good market versatility, which can be easily adapted to cables and equipment interfaces of the same specification, reducing procurement and adaptation difficulties.
-
Push Locking Design: Innovatively adopts a push locking fixing mechanism, which enables convenient and efficient plug-in operation. It can be locked with a light push, effectively preventing connection loss caused by accidental pulling and vibration, and ensuring the continuity of power transmission; the unlocking process is simple and labor-saving, facilitating later equipment maintenance and cable replacement.
-
ROHS Environmental Certification: Fully complies with ROHS environmental standards. The production process of the connector strictly controls the use of harmful substances such as lead and mercury, taking into account both product performance and environmental protection needs. It is suitable for industry scenarios with clear environmental protection requirements, such as home appliance manufacturing, new energy supporting facilities, and medical equipment auxiliary fields.
Main Feature
- Push lock quick release system
- Multic-core options: 2Pin,3Pin,4Pin,5Pin,3+2Pin,3+3Pin,3+9Pin,3+13Pin,5+2Pin and 2+20Pin available
- Field assembly version:both wire to wire and wire to board options
- High current rated waterproof connector good choice up to 50A for long time working
- Cable assembly service supported, welcome to custom
- OEM/ODM welcome
| Electrical Parameters | |
| Number of Poles | 4Pin waterproof connector |
| Current Rating | 50A max |
| Voltage Rating | 600VAC max |
| Durability Voltage | 2500VAC @ 60 s. |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Application industries
- Communications Application
- product coding machines
- inventory product coding
- inkjet systems
- Solar System
- industrial inkjet equipment
- Electric power equipment
- Laboratory forensic&pathology equipment
- Communications equipment
- Heavy machinery
| Operation Parameters | |
| Voltage Rating | 600VAC max |
| Current Rating | 30A max |
| Min Wire Size OD | 6.5mm ~ 10mm |
| Max Wire Size OD | 10.5mm ~ 18mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 6.0mm2 |
Production Dimension
More Technical Details
