M19 10Pin Waterproof Outdoor Connectors Low Power Signal Plug And Socket Connector
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
3~6working days
Brand:
Ulinkcon
Product Description
M19 10 Pin Waterproof Quick Disconnect Wire To Board Connectors
Quick Description
-
Scenario Adaptation Positioning: Customized specifically for outdoor low-power signal transmission scenarios, adopts M19 standard circular structure, paired with male-female plug and socket design, 10Pin multi-channel layout can simultaneously carry multiple groups of low-power signals, adapting to signal collection and transmission needs in complex outdoor environments
-
Core Signal Specifications: Interface specification M19, equipped with 10Pin signal-dedicated pin cores, focusing on low-power signal transmission, supports male-female quick docking, precise pin positioning to avoid signal misconnection, meeting the basic needs of parallel transmission of multiple groups of signals
-
Outdoor Protection Design: Adopts integrated waterproof sealing structure, effectively resisting outdoor rain erosion, dust intrusion, dew condensation and ultraviolet radiation; the shell is made of weather-resistant engineering plastic, with excellent high and low temperature resistance (-40℃~105℃) and anti-aging performance, adapting to complex outdoor climate environments
-
Signal Transmission Performance: Optimized design for low-power signals, the pin cores adopt brass gold-plating process, with extremely low contact resistance, low signal transmission loss and strong anti-interference ability, which can effectively avoid distortion and attenuation problems during low-power signal transmission and ensure signal transmission clarity
-
Male-Female Connection Advantages & Applications: The male-female plug and socket adopt snap-on connection design, with smooth plugging and firm locking, excellent anti-vibration and anti-fall performance; widely used in outdoor sensor signal collection, intelligent security monitoring signal transmission, outdoor lighting control systems, portable electronic equipment signal docking, environmental monitoring instruments and other low-power signal outdoor connection scenarios
| Electrical Parameters | |
| Number of Poles | 10Pin |
| Current Rating | 5A max. |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1500VAC @ 60 s. |
Application industries
- Growth Lights
- Communications Application
- product coding machines
- inventory product coding
- inkjet systems
- Solar System
- industrial inkjet equipment
- Electric power equipment
- Laboratory forensic&pathology equipment
- Communications equipment
- Heavy machinery
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Main Features
- Push lock quick release system
- Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
- 3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
- 6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
- Field assembly version:both wire to wire and wire to board options
- Cable assembly service supported, welcome to custom
- OEM/ODM welcome
| Operation Parameters | |
| Voltage Rating | 300VAC max |
| Current Rating | 5A max |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 2.5mm2 |
Design Sketch
FAQ
1. Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District,Shenzhen,China
2. Q: How can I get samples?
A: It's my honor to offer you samples,and the freight should be paied by yourself.You can let me know your courier number and your detail address,Then I can send you sample at once.
3. Q: How many materials you can provide?
A: There's some different materials from connector and cable, we usually use PVC/Nylon material to product connector, PVC/Rubber/Silicone material was used in cable. Of course we can also according to your requirments to choose the material.
