Male And Female Wire Connector M19 6 Pin Outdoor Waterproof Connectors For Data
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
3~6 working days
Brand:
Ulinkcon
Product Description
M19 6-Pin Outdoor Waterproof Data Connector
Product Overview
This industrial-grade M19 6-pin waterproof connector is specifically engineered for outdoor data transmission applications. Featuring excellent sealing performance and stable conductivity, it provides reliable data connections for outdoor electronic equipment. The male-female pairing design ensures precise 6-pin core connections for efficient transmission of various low-current data signals.
Key Features
- IP67 rated waterproof and dustproof protection
- Push-lock quick release system for easy installation
- High-conductivity brass terminals with gold plating
- Wide operating temperature range: -40°C to +105°C
- Weather-resistant PA66 housing material
- Multiple pin configurations available (2-20 pins)
- Wire-to-wire and wire-to-board assembly options
- 10A maximum current rating for continuous operation
- Custom cable assembly and OEM/ODM services available
Electrical Specifications
| Number of Poles | 6-pin configuration |
| Current Rating | 10A maximum |
| Voltage Rating | 300V AC maximum |
| Durability Voltage | 1000V AC @ 60 seconds |
Technical Specifications
| Contact Resistance | 10 mΩ maximum |
| Insulation Resistance | 500 MΩ at 500V DC |
| Operating Temperature | -40°C to +105°C |
| IP Rating | IP67 (1 meter / 30 minutes) |
| Housing Material | PA66 |
| Contact Material | Gold-plated brass |
| Seal Material | Silicone |
Application Industries
- Communications equipment
- Industrial inkjet systems and coding machines
- Solar power systems
- Electric power equipment
- Laboratory and forensic equipment
- Heavy machinery
- Security monitoring systems
- Smart agriculture
- Industrial automation
- New energy equipment
Product Dimensions
Technical Details
Frequently Asked Questions
What is rated voltage?
Rated voltage, also known as operating voltage, depends on the connector's insulation material and contact spacing. Some components may not function properly below their rated voltage specification.
Are your products certified? What certifications do you have?
All our products are certified by RoHS, CE, and other international standards. Specific certifications (e.g., FCC, UL) can be provided upon request based on your target market requirements.
What is your Minimum Order Quantity (MOQ)?
The MOQ varies by product type—typically 500 units for standard models and 1000 units for customized items. Lower MOQ can be negotiated for trial orders or long-term cooperation agreements.
