IP67 3 Pin Male Female Connectors M19 20A Industrial Circular Connector
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
3~6working days
Brand:
Ulinkcon
Product Description
M19 3 Pin 300V Waterproof Cable Connector Quick Lock For Power
Main Features
- Item Name : M19 Waterproof Cable Connector
- Specifications : Straight male-female mating, elbow male-female mating, front-mounted wire -to- board, rear-mounted wire -to-board,integrated injection molding
- Coupling way: Self-locking
- Pins number :2-22 pins
- Plug : Assembly type and Injection type available
- Socket: Front Mount, Back Mount, PCB Mount
- Waterproof grade: IP67/ IP68
- Connector type :Assembly lock screw；Assembly welding；Injection molding with cable
- Wire gauge: 1.0-6.0mm² (18AWG-10AWG)
- Wiring range Assembled: 6. 0mm~16mm；Molding 6. 0mm~16.5 mm
- Durability :3000 times
- Applicabletemperature: -40℃~105℃
Quick Description
-
Product Model & Basic Overview: Model is IP67 3 Pin Male Female M19 Industrial Circular Connector, with a rated current of 20A, specially developed for industrial power and signal transmission scenarios. It adopts a male-female mating design, featuring compact structure, reliable performance, and strong environmental adaptability, widely recognized by industrial connector manufacturers and users.
-
Core Electrical Parameters: Rated voltage is 300V AC, rated current reaches 20A, which can stably transmit power and signal for medium and low-power industrial equipment. The contact resistance is ≤10mΩ.
-
Waterproof & Dustproof Performance: Complies with IP67 protection rating, which means it is completely dust-tight and can be temporarily immersed in 1m deep water for 30 minutes without water intrusion, effectively blocking rain, dust, moisture, and even corrosive substances, ensuring stable operation in harsh industrial environments.
-
Operating Environment Adaptability: Works stably in the temperature range of -40℃ to +105℃, adapting to extreme weather conditions such as severe cold, high temperature, and large temperature differences. It is UV-resistant, oil-resistant, and corrosion-resistant, suitable for long-term use in outdoor and industrial harsh environments such as factories, construction sites, and marine areas.
-
Application Scenarios: Widely used in various industrial fields, including industrial automation equipment, construction machinery, marine equipment, agricultural machinery, LED lighting systems, solar energy equipment, stage equipment, and industrial control systems, providing reliable power and signal connection support for various industrial devices.
-
Certification & Quality Assurance: Passed international certifications such as CE, ROHS, TUV, and UL, meeting global industrial safety and environmental protection standards. Manufactured with strict quality control processes, the product has a mating durability of no less than 5000 cycles and a service life of 3-5 years, ensuring long-term reliable use for users.
| Electrical Parameters | |
| Number of Poles | 3 pin |
| Current Rating | 20A max. |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1500VAC @ 60 s. |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
| Operation Parameters | |
| Voltage Rating | 600VAC max |
| Current Rating | 15A max |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 2.5mm2 |
Design Sketch
