PA66 M19 3+9 Pin Signal And Power Connectors IP67 Circular Panel Mount Connector
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
5~8 working days
Brand:
Ulinkcon
Product Description
M19 3+9 Pin Waterproof Self Locking Cable To Board Connector IP67
Product Overview
Quick Release Wire Connector M19 3+9 Pin OEM Waterproof 300V Connector
Key Features
-
Core Specifications: Adopts M19 size design with 3+9 Pin configuration, realizing integrated transmission of power and signal. It eliminates the need for additional two types of connectors, effectively saving installation space, adapting to equipment scenarios with limited space, and solving the inconvenience of separate connection of power and signal.
-
Protection Level: Reaches IP67 waterproof and dustproof standard. It can achieve complete dustproof in the mated state and can be immersed in 1-meter deep water for 30 minutes without affecting use. It can effectively resist erosion from harsh environments such as moisture, dust and splashing water, ensuring stable operation of equipment.
-
Material & Craftsmanship: The shell is made of PA66 nylon material reinforced with glass fiber, complying with UL94 V-0 flame retardant grade, featuring high temperature resistance, impact resistance and corrosion resistance, and not easy to deform or age. The contacts are made of brass with gold plating, which reduces contact impedance, improves conductivity and corrosion resistance, and extends service life.
-
Installation Method: Adopts circular panel mount design, which is easy and stable to install, suitable for various panel thicknesses, and can be widely used for fixed installation of equipment panels. It also supports welding connection method, with reliable connection, not easy to fall off, and high assembly efficiency.
-
Application Scenarios: Suitable for various fields such as industrial automation, outdoor LED lighting, marine equipment, medical equipment, solar energy equipment and security monitoring, especially suitable for power supply and signal transmission needs in outdoor and harsh industrial environments.
Technical Specifications
Product Type Features
| Connector System | Cable-to-Board |
|---|---|
| Sealable | Yes |
| Connector & Contact Terminates To | Wire & Cable |
| Circular Connector Type | Plug, Receptacle |
| Shell Type | Plastic Shell |
| Product Type | Connector Kit |
Electrical Characteristics
| Number of Poles | 3+9 |
|---|---|
| Current Rating | 15+5A max |
| Voltage Rating | 600VAC max |
| Durability Voltage | 2500VAC @ 60 s |
Body Features
| Shell Material | PA66 |
|---|---|
| Circular Connector Insulation Material Type | Low Fire Hazard Thermoplastic |
| Hermetically Sealed | Yes |
| Entry Style | Side |
| Environmental Protection Type | Elastomer Sealed, Hermetically Sealed |
| O-Ring Material | Elastomer Sealed, Hermetically Sealed |
| Environmental Protection | Yes |
Usage Conditions
| Operating Temperature Range | -40°C to 105°C |
|---|---|
| IP Water Sealing Level | IP67 |
| IP Dust Sealing Level | 6 |
| Durability Rating (Cycles) | 250, 251 |
| UL Flammability Rating | UL 94V-0 |
Configuration Options
- Multic-core options: 2Pin, 3Pin, 4Pin, 5Pin for Power
- 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin for power signal combined
- 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin for signal available
- Field assembly version: both wire to wire and wire to board options
- Current rated 20A for long time working
- Cable assembly service supported
- OEM/ODM welcome
Application Industries
- Communications Application
- Product coding machines
- Inventory product coding
- Inkjet systems
- Solar System
- Industrial inkjet equipment
- Electric power equipment
- Laboratory forensic & pathology equipment
- Communications equipment
- Heavy machinery
Product Dimensions
Technical Details
Frequently Asked Questions
Q1: What is rated voltage?
A1: Rated voltage also known as operating voltage, which mainly depend on the connector insulation material used, the spacing between the size of contact. Some of the components or devices in less than its rated voltage may not be completed to its functions.
Q2: How to track my shipment?
A2: Once the goods are shipped, we will send you the tracking number and logistics platform link. You can track the real-time status online or contact our team for updates.
Q3: Are you a factory or trading company?
A3: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District,Shenzhen,China
