15A 4 Pin Electrical Wire To Wire Connectors M19 PA66 Plastic Waterproof Power Connector
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
3~6working days
Brand:
Ulinkcon
Product Description
IP67 Waterproof M19 4 Pin Male To Female Outdoor Connector
Quick Description
-
Core Electrical Parameters: Adopts M19 circular package size with 4Pin design, rated current 15A, rated voltage 300V (suitable for low-voltage power transmission scenarios). The pin spacing is precisely controllable, with contact resistance ≤10mΩ, insulation resistance ≥500MΩ, and withstand voltage 500V AC/1min, ensuring efficient and stable power transmission to meet the power supply needs of medium and low-power equipment.
-
Material & Structural Craftsmanship: The shell is made of PA66 reinforced nylon material, modified with glass fiber, complying with UL94 V-0 flame retardant grade. It has excellent high and low temperature resistance (-40℃~105℃), impact resistance, chemical corrosion resistance and anti-aging performance, which can adapt to harsh industrial environments. The contacts are made of high-conductivity brass substrate, with tin plating (gold plating optional) on the surface, improving conductivity and oxidation resistance, and eliminating the hidden danger of poor contact.
-
Waterproof Protection Design: Adopts an integrated fully sealed structure, equipped with fluororubber waterproof sealing ring, reaching IP67 protection level. It can achieve complete dustproof and short-term water immersion (1m water depth/30min) protection, effectively isolating the intrusion of water vapor, dust, oil stains and other impurities, ensuring the long-term stable operation of the connector in outdoor, wet workshop and other scenarios.
-
Wire-to-Wire Connection Characteristics: Specifically designed for wire-to-wire docking scenarios, adopting plug-in quick connection structure with anti-misplug positioning key, which can effectively avoid equipment damage caused by reverse pin connection. The wiring method supports crimping/welding dual options, and the crimp terminal is suitable for 0.5-2.5mm² wires, with firm connection, reliable contact, high assembly efficiency, and easy later maintenance and replacement.
-
Reliability & Compliance: The product has passed strict aging tests, high and low temperature cycle tests, waterproof tests and electrical performance tests, complying with international standards such as RoHS and CE. The mechanical life is ≥1000 insertions and extractions, with excellent contact stability, which can effectively reduce equipment failure rate and is suitable for power transmission scenarios with high requirements for connection reliability.
-
Professional Application Scenarios: Widely used in industrial automation equipment, outdoor power equipment, new energy charging pile auxiliary power supply, marine electrical equipment, security equipment power supply, vehicle-mounted low-voltage systems and other fields. It is mainly used for wire-to-wire power transmission of medium and low-power equipment, especially suitable for outdoor, wet and other scenarios with strict requirements for waterproof and material durability.
Main Features
- Push lock quick release system
- Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
- 3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
- 6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
- Field assembly version:both wire to wire and wire to board options
- Current rated 15A for long time working
- Cable assembly service supported, welcome to custom
- OEM/ODM welcome
| Electrical Parameters | |
| Number of Poles | 4Pin |
| Current Rating | 15A max. |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1000VAC @ 60 s. |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
| Operation Parameters | |
| Voltage Rating | 600VAC max |
| Current Rating | 15A max |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 2.5mm2 |
Application industries
- Growth Lights
- Communications Application
- product coding machines
- inventory product coding
- inkjet systems
- Solar System
- industrial inkjet equipment
- Electric power equipment
- Laboratory forensic&pathology equipment
- Communications equipment
- Heavy machinery
Design Sketch
FAQ
1. Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District,Shenzhen,China
2. Q: Do you support product customization?
A: Yes, customization is available for specifications, colors, logos, and packaging. Please provide your detailed requirements, and we will quote accordingly with a sample confirmation process.
3. Q: Can I pay after receiving the goods?
A: For first - time cooperation, advance payment is required to ensure production smoothness. For long - term trusted clients, flexible payment terms can be discussed after several successful orders.
