M19 IP67 18 Pin Cable Connector Outdoor Waterproof Quick Connector To Communications Equipment
Price:
Negotiation
MOQ:
Negotiation
Delivery Time:
3~6working days
Brand:
Ulinkcon
Product Description
IP67 Waterproof Connectors M19 18 Pin Wire To Board For Data
Product Overview
18 Pin Cable Connector M19 Wire To Wire / Board Outdoor Quick Lock Signal Connectors
Key Features
-
Specification: M19 standard, 18-pin design, specially adapted for signal transmission of communication equipment
-
Protection: IP67 waterproof and dustproof, resistant to outdoor rain and dust, suitable for harsh outdoor environments
-
Connection: Quick-connect design, smooth plugging and firm locking, improving on-site installation and maintenance efficiency
-
Transmission: Pins made of high-conductivity material, stable signal transmission, reducing interference and attenuation
-
Durability: UV-resistant, impact-resistant shell, high and low temperature resistant, suitable for long-term outdoor use
-
Application: Directly connect to various outdoor communication equipment, such as base stations, outdoor switches, etc.
Technical Specifications
| Parameter | Specification |
|---|---|
| Number of Poles | 18Pin |
| Current Rating | 5A max. |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1500VAC @ 60 s. |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max Cable Cross Section Area | 0.5mm² ~ 2.5mm² |
Configuration Options
- Push lock quick release system
- Multic-core options: 2Pin, 3Pin, 4Pin, 5Pin for Power
- 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin for power signal combined
- 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin for signal available
- Field assembly version: both wire to wire and wire to board options
- Current rated 5A for long time working
- Cable assembly service supported
- OEM/ODM welcome
Application Industries
- Growth Lights
- Communications Application
- Product coding machines
- Inventory product coding
- Inkjet systems
- Solar System
- Industrial inkjet equipment
- Electric power equipment
- Laboratory forensic & pathology equipment
- Communications equipment
- Heavy machinery
Product Design
Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
Q: How to buy your products?
A: You need to do as followings:
- Confirm Current Rating and Number of Contacts
- Confirm Assembly style
- Confirm Cable Wire gauge
- Confirm Cable Length and Material
Q: Are your products certified? What certifications do you have?
A: All our products are certified by RoHS, CE, and other international standards. Specific certifications (e.g., FCC, UL) can be provided upon request based on your target market.
