20A 5 Pin Power Waterproof Cable Connector M19 Industrial Male Female Push Lock Connector
High Current 5 Pin Cable M19 PA66 300V Male To Female Waterproof Power Connector
Main Features
- Push lock quick release system
- Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
- 3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
- 6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
- Field assembly version:both wire to wire and wire to board options
- Current rated 20A for long time working
- Cable assembly service supported, welcome to custom
- OEM/ODM welcome
Quick Description
1. 20A High Current Industrial Power Performance
-
The integrated 5-pin layout realizes multi-circuit centralized power conduction, effectively meeting the wiring requirements of high-power equipment circuits. It features low temperature rise and zero voltage attenuation during power transmission.
2. Tool-free Push Lock & Male Female Quick Connection
-
Built-in anti-loosening limit buckle ensures tight and stable connection after locking. It resists equipment vibration and slight wire pulling, preventing poor contact and power interruption in industrial working environments.
3. Superior Waterproof & Dustproof Industrial Protection
-
It adapts to harsh environments such as outdoor exposure, rain and snow weather, humid workshops and dusty industrial sites, preventing terminal oxidation and short circuit caused by moisture and dust accumulation.
4. Sturdy & Durable Industrial-Grade Material
-
Thickened high-purity conductive pins feature high conductivity and low impedance, ensuring lossless high-current transmission. The pins are anti-oxidation and anti-corrosion for long-term service in complex industrial environments.
5. Wide Application Range
-
Ideal for industrial cable connection scenarios requiring high-current power supply, quick locking connection and outdoor waterproof & dustproof performance.
| Electrical Parameters | |
| Number of Poles | 5Pin |
| Current Rating | 20A max. |
| Voltage Rating | 300VAC max |
| Durability Voltage | 1000VAC @ 60 s. |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) when mated |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
| Operation Parameters | |
| Voltage Rating | 600VAC max |
| Current Rating | 15A max |
| Min Wire Size OD | 3.0mm ~ 6.0mm |
| Max Wire Size OD | 8.0mm ~ 10.0mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 2.5mm2 |
Application industries
- Growth Lights
- Communications Application
- product coding machines
- inventory product coding
- inkjet systems
- Solar System
- industrial inkjet equipment
- Electric power equipment
- Laboratory forensic&pathology equipment
- Communications equipment
- Heavy machinery
Design Sketch
FAQ
1. Q: Is there a discount for large - quantity orders?
A: Yes, we offer tiered discounts for bulk orders. The more you order, the more competitive the price. Please inform us of your expected quantity for a customized quotation.
2. Q: Are your products certified? What certifications do you have?
A: All our products are certified by RoHS, CE, and other international standards. Specific certifications (e.g., FCC, UL) can be provided upon request based on your target market.
3. Q: Can I have custom label?
A: Yes,of course,you can make you own private label and package,if you need to design the packaging ,we also have professionaldesigner to serve you.
