First, the structure is high strength aluminum alloy profile or steel
■ High strength aluminum alloy profile tensile strength 215 N/M square meters
■ GB Q235 steel silver metal surface paint
Second, the tarpaulin is a double PVC synthetic fiber tarpaulin or building film material
■ Fiber high strength polyester 1100 Dtex
■ Weight NF EN ISO2286-2 standard 650 g/m2
■ Tensile strength (warp/weft) NF EN ISO1421 standard 280/260 daN/5cm
■ Tear strength (warp/weft) DIN 53.363 standard 28/25 da
■ Light transmittance NFG 38.511 standard 13%
■ Applicable temperature -30℃ /+70℃
■ Fire response DIN 4102 Class B1

There are several ways to fix the canopy:

■ Steel fastening
Use steel to secure the tent on grass, asphalt or other soft ground.
■ Expansion bolt fixed
Secure the tent to the concrete floor using expansion bolts.
■ Fixed with weights
If the field is not allowed to use steel or expansion screws can use cement pier, water tank and
Sandbags to secure the tent.
■ Load-bearing floor system
Use a load-bearing floor system to secure the canopy, eliminating the need for additional steel or expansion screws.
■ Embedded parts fixed
For large bungalows with a long use time, it is necessary to make foundation embedded parts, tent structure and
Embedded part connection.
