Fashion Large Easy Up Outdoor Party Tents Bay Distance 5m Canopy Party Tent
Fashion Large Easy Up Outdoor Party Tents Bay Distance 5m Canopy Party Tent
Product Specification:
|
Span Width
|
3m/4m/5m/6m/8m/9m/10m/12m/15m/18m/20m/25m/30m/ 40m/50m |
|
Ridge Height
|
3.2m/3.4m/3.6m/3.7m/4.m/4.3m/4.4m/4.8m/6.4m/6.9m/7.2m/ 8.0m/8.9m/10.6m/12.3m |
| Longest Component | 2.9m/3.9m/4.9m/3.6m/4.3m/4.8m/5.3m/6.3m/ 8m/9.6m/10.7m |
| Side Height | 2.6m/3m/4m |
| Roof Pitch | 18°/20° |
| Bay Distance | 3m/5m |
| Maximum Length | No limit |
| Main Profile |
84X48X3mm/100X48X3mm/122X68X3mm/166X88X3mm/ 204X110X4mm/256X113XSmm/300X125X6mm/350X125X8mm aluminum alloy |
| Frame Material | High reinforced aluminum,anti-rust surface, GB/T 6061-T6 standard,Surface oxidation;Film thickness>10|jm |
| Fabric Material | 850g/m2double PVC-coated polyester,flame retardant,UV resistance,waterproof,comply with DIN 4102 B1,M2 (German standard),Applicable temperature range:-30°C to +70 °C |
Tent classification :
The tent has a variety of styles, which can be divided into three types according to different shapes:
1, the first is the most common A-frame tent. The activity canopy has the largest span and the most widely used, from outdoor commercial promotion
All the way to the big show.
2, the second is the pointed canopy room. The bottom is square, and the roof is like a spire. Elegant in appearance.
3, the last kind of mixed common A-frame canopy and pointed canopy, further improve the appearance of the effect.
Characteristic function :
High weakness pure aluminum alloy frame structure, without any pillar in the middle, the space can be 100 percent of the application; Entrance double PVC synthesis Tarpaulin, highly effective UV protection, flame retardant (B1, M2 level), rain, wind (8 level).
Fixed mode :
Fixed method 1: steel (suitable for the ground situation is soft soil, such as: grass, soft mud);
Fixing method 2: expansion screws (The ground is suitable for playing expansion screws when the cement floor can be destroyed, and can also be lowered Low cost, but to ask for on-site power supply);
Fixed method 3: load bearing plate attached weight, can be attached to heavy cement blocks, sand. (suitable for the ground can not be damaged);
RFQ :
Q1. How Long Will a TENDARS Clear Span Structure Last?
In the reasonable using, the lifespan of the aluminum alloy can last over 30 years and the PVC cover is guaranteed up to 5 years. And TENDARS will offer you an affordable price for component replacing.
Q2. Can TENDARS Tent Structure be Relocated?
All of our tent structures is designed into relocatable construction. For the seasonal and regional using, you can dismantle, store or remove the tent to any location. Also, our tent structures are allowed to be permanent building as sports center, industrial warehouse or exhibition hall.
Q3. Can I Expand the Tent Size or Replace the Accessories of the Tent Structures in the Future?
Sure. All of our tent structures and accessories are made into modularity. You can expand the tent length by adding bay distance (the distance should be in original length) unlimitedly. Also, the accessories can be replaced into a new one, we will offer affordable price of components replacement to our clients.
