Product Specification:

Tent technology requirements  :

1.1 In order to standardize the construction of temporary tents for the exhibition, meet the use function, reliable technology, safe and applicable,
Economical and reasonable, to ensure the quality of the project and the use of safety, the formulation of this regulation.

1.2 This standard applies to the single layer with a span of no more than 40m used in temporary rooms of exhibition projects
Tent design, manufacture, installation, use and maintenance. When the monomer span is greater than 40m, or the height is greater than 2
Layer (including 2 layers) and if there are special requirements, experts should be organized to conduct safety demonstration.

1.3 In addition to this standard, the application of temporary tents should also meet the current national and local standards
Standard and normative requirements.

2 Art language

2.1 Tent
Reusable, movable, closed or open temporarily installed structural buildings, consisting of support structures and enclosures
Protective structure composition.
2.2 Structural Components
The main force components of the tent, such as: beams, columns, plates, supports, stairs, platforms and other components.
2.3 Enclosure Structure
Enclosures on all sides of the tent, such as walls, roofs, doors and Windows.
2.4 Membrane material
A composite material consisting of a high-strength fabric substrate and a polymer coating.

3 A general rule

3.1 Qualification documents: The tent should have factory qualification documents or relevant test reports. Certificate of conformity
The documents shall indicate the product model specification, batch number, manufacturer name, production year, technical verification agency,
Combustion characteristics and other necessary information.
3.2 The design, manufacture and installation of the tent must ensure the safety of the structure.
3.3 The materials used in the enclosure structure and interior decoration of the tent must meet the fire protection grade B1 and above.
Safety cables for pillar structures must be made of non-combustible materials.
3.4 When the span of the canopy is less than or equal to 12m, the wind resistance performance is not less than 60km/h wind resistance. tent
When the span is greater than 12m, the wind resistance is not less than 80km/h wind resistance.
3.5 The tent should have adequate energy saving measures.
3.6 Waterproof and drainage measures should be considered according to the needs of the tent.
