FRC-1-2-D-MIDI Filter Regulator Lubricator Oil Pneumatic Compressor
FESTO FRC-1-2-D-MIDI
Oil Filter Regulator Lubricator E-10~+60C Pneumatic
Product Description:
FRC / AW / AFR / BFR type air filter regulator and pressure gauge
It includes 2 parts: filter & regulator and lubricator.
But still have 3 function: filtration, decompression and lubricating.
Auto Drain can be selected. All size have overflow function.
The Pneumatic Filter Regulator Lubricator is an air filter regulating device that is designed to ensure efficient filtration and accurate air pressure regulation. This device is lightweight, weighing only 200g, and has a threaded connection for easy installation. The lubricator element is made of oil, and the operating temperature is from -10℃ to +60℃. It is an excellent choice for applications requiring precise filtration, as it has a filtration grade of 40μm. The Pneumatic Filter Regulator Lubricator is a reliable and durable air filter regulating device that is suitable for many industries.
Features:
- Product Name: Pneumatic Filter Regulator Lubricator
- Regulator Element: Diaphragm
- Type: Filter Regulator Lubricator
- Weight: 200g
- Air Filter Regulator: Yes
- Air Filter Lubricator: Yes
- Air Filter Lubricator Regulator: Yes
Technical Parameters:
| Parameter | Value |
|---|---|
| Product Name | Pneumatic Filter Regulator Lubricator |
| Type | Filter Regulator Lubricator |
| Material | Stainless Steel |
| Regulator Element | Diaphragm |
| Flow Rate | 650~8,200 L/min |
| Weight | 200g |
| Voltage | 12V |
| Grade of filtration | 40 μm |
| Operating Temperature | -10~+60℃ |
| Connection Type | Threaded |
| Operating and environmental conditions Condensate drain |
Manual | Fully automatic |
| Operating pressure [bar] | 1 ... 16 (0.1 ... 1.6 MPa) | 2 ... 12 (0.2 ... 1.2 MPa) |
| Operating medium | Compressed air to ISO 8573-1:2010 [–:–:–] | |
| Inert gases | ||
| Ambient temperature [°C] | –10 ... +60 | |
| Temperature of medium [°C] | –10 ... +60 | |
| Corrosion resistance class CRC^{1)} | 2 | |
Characteristics:
1. Strong pressure resistance, pressure resistance up to 1.6MPA.
2. The whole material is made of aluminum alloy, which has stable performance and durability.
3. The diaphragm has good resistance to oil and heat.
4. Double pressure scale, MPA / BAR reading is convenient and the display is more accurate.
5. Complete accessories, not easy to rust.
Customization:
Brand Name: Festo
Model Number:FRC-3/4-D-7-MIDI-MPA
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Carton /As The Clients Require
Delivery Time: 1-7Work Days After Payment
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 5000PCs per month
Product Name: Pneumatic Filter Regulator Lubricator
Operating Temperature: E-10~+60℃
Flow Rate: 650~8,200 L/min
Weight: 200g
Filter Element: 5 Micron
Specialty: Air Filter Lubricator, Air Filter Regulator, Air Filter Regulator Lubricator
