JA Series JA10-4-070 SMC Solenoid Valves for Air and Hydraulic Cylinders

Product Description:

The product has been designed to provide superior functionality while also simplifying the installation process. The following are some of the design features that make it stand out:

• Floating joint design that can absorb the eccentricity between the passive body and the cylinder, as well as the insufficient accuracy of parallelism.
• No need for axis alignment, making installation easier.
• High-temperature specification suitable for working environments ranging from -5 ℃ to 60 ℃, ensuring connection stability under extreme temperatures.
• High load handling capacity with a maximum applied tensile force on both the compression and tension sides being 28000 N, demonstrating excellent load bearing capacity.

The technical specifications of the product are as follows:

• Installation form: Basic type that offers a stable connection method 2.
• Suitable cylinder diameter: 100mm, making it compatible with cylinder 1 that has a diameter of 100mm.
• Thread specification: M26X1.5, which is a standard thread specification making it easy to connect with cylinders and other pneumatic components.
• Swing angle: ± 5 °, allowing a certain eccentricity of 0.5mm, providing greater flexibility and adaptability.
• Pressure range: 0.05-1 MPa, suitable for various working pressures.
• Environmental temperature and fluid temperature: -5~60 ℃, suitable for various working environments.

Technical Parameters:

SMC floating joint and SMC JA Series Floating Joints are suitable for this product. Additionally, cylinder exhaust tailpipe joint can also be used with this product.

Applications:

SMC's JA series floating joints are ideal for various applications such as:

• Pneumatic and Hydraulic Systems: The joints are suitable for connecting cylinders and hydraulic cylinders in situations where eccentricity and parallelism need to be absorbed.
• Automated Machinery: In automated machinery, the joints are used to connect cylinders and driven bodies, ensuring stable operation of the system.
• Handling System: The joints are used to ensure stable operation of cylinders in the handling system, increasing handling efficiency.

SMC's JA series floating joints are highly regarded in the market for their excellent design and performance. They are widely used in the industrial automation field, providing an efficient and flexible connection solution for pneumatic systems. Users have given high praise to the product, highlighting the following:

• Absorption of eccentricity and insufficient parallelism
• High temperature tolerance
• High load response ability

User evaluation confirms that the floating joints provide a stable and reliable pneumatic connection solution.

Overall, SMC's JA series floating joints provide an efficient and reliable solution for connecting pneumatic and hydraulic systems with their excellent design and performance.
