SMC JA Series JA100-26-150 Air And Hydraulic Cylinder Fit Connection
Product Description:
One of the design challenges of traditional joints is the insufficient absorption of eccentricity and parallelism, which hinder their installation process and performance. However, the floating joint design can solve this problem by absorbing the eccentricity between the passive body and the cylinder, and the insufficient accuracy of parallelism. With this design, there is no need for axis alignment, simplifying the installation process.
Another notable feature of this floating joint is its ability to function in high-temperature environments ranging from -5 ℃ to 60 ℃, ensuring connection stability under extreme temperatures. This temperature specification makes it ideal for use in challenging work environments.
The joint also demonstrates excellent load-bearing capacity with a maximum applied tensile force of 28000 N on both the compression and tension sides, suitable for high-load handling.
- Installation form: Basic type, providing stable connection method 2.
- Suitable cylinder diameter: 100mm, suitable for cylinder 1 with a diameter of 100mm.
- Thread specification: M26X1.5, standard thread specification, easy to connect with cylinders and other pneumatic components.
- Swing angle: ± 5 °, allowing a certain eccentricity of 0.5mm, providing greater flexibility and adaptability.
- Pressure range: 0.05-1 MPa, suitable for various working pressures.
- Environmental temperature and fluid temperature: -5~60 ℃, suitable for various working environments.
Technical Parameters:
| Series | JA Series |
| Connection Type Cylinder Side | Tapped |
| Type | Fittings |
| Cylinder Used | Air Cylinder / Hydraulic Cylinders |
| Connection | Flange |
| Color | Black |
SMC floating joint and SMC JA Series Floating Joints are compatible with this product. The applicable cylinder thread size is also supported.
| JA6-3-050 | JA80-20-150 |
| JA10-4-070 | JA80-20-250 |
| JA15-5-080 | JA80-22-150 |
| JA15-6-100 | JA100-24-300 |
| JA20-8-100 | JA100-26-150 |
| JA20-8-125 | JA100-27-150 |
| JA20-8-150 | JA100-27-200 |
| JA25-10-150 | JA125-27-200 |
| JA30-10-125 | JA140-30-150 |
| JA32-10-100 | JA160-30-200 |
| JA40-12-125 | JA160-33- 200 |
| JA40-12-150 | JA160-36-150 |
| JA40-12-175 | JA160-36-200 |
| JA40-14-125 | JA180-40-150 |
| JA40-14-150 | JA180-40-200 |
| JA63-16-150 | JA180-42-150 |
| JA63-16-200 | JA180-42-200 |
| JA63-18-150 |
Applications:
SMC’s JA series floating joints are ideal for connecting cylinders and hydraulic cylinders, especially in situations where eccentricity and parallelism need to be absorbed. These floating joints provide a flexible, efficient connection solution for pneumatic systems.
Automated machinery relies on the stable operation of connections between cylinders and driven bodies, for which the JA series floating joints are widely used. These joints ensure a stable operation of the system, helping to improve overall efficiency and performance.
The JA series floating joints are designed to ensure the stable operation of cylinders in handling systems. By providing a reliable connection solution for pneumatic systems, these joints can help improve the efficiency of handling and transport processes.
SMC's JA series floating joints are widely recognized and trusted by the industrial automation market. These floating joints have an excellent design and performance that provides an efficient and flexible connection solution for pneumatic systems.
Users of SMC's JA series floating joints have given high praise and positive reviews. The joints perform well in absorbing eccentricity and insufficient parallelism, can tolerate high temperatures, and have a high load response ability, providing a stable and reliable pneumatic connection solution to its users.
In summary, SMC's JA series floating joints provide an efficient and reliable solution for connecting pneumatic and hydraulic systems with their excellent design and performance, making them a popular choice in the field of industrial automation.
