Product Description:

The main properties of the CY1L series rodless cylinder include cylinder diameter, stroke, material, temperature range, function, etc.

Cylinder diameter and stroke

The cylinder diameter range of CY1L series rodless cylinder is from 10mm to 40mm, and the stroke range is from 100mm to 1000mm.

Material and temperature range

The material of the CY1L series rodless cylinder is mainly aluminum alloy, which can work in ambient temperatures ranging from -10 ℃ to 60 ℃ and adapt to various industrial environments.

Function and Features

• The CY1L series rodless cylinder is widely used for linear motion control in pneumatic systems.
• It features high accuracy, stable operation, low noise, and smooth motion.
• The cylinder has various mounting options, such as front flange mounting and rear clevis mounting.
• It is equipped with a high-strength piston rod and a sealing system to prevent dust and water from entering the cylinder.

Applications:

The CY1L series rodless cylinder is a highly efficient and energy-saving solution suitable for a wide range of motion control scenarios. This cylinder operates in a double-acting mode, using fluid as air and cushioning to effectively absorb impact while protecting the cylinder and the load it carries.

One of the key features of the CY1L series is its unique cushioning system. This design helps to minimize wear and tear on the cylinder and also reduces the amount of noise generated during operation. Additionally, this series boasts a non-oil supply design that helps to further reduce maintenance costs and minimize the risk of environmental pollution.

If you're looking for a durable and cost-effective solution for your motion control needs, the CY1L series rodless cylinder is definitely worth considering. With its innovative design and advanced features, you can rest assured that this product will perform reliably and efficiently for years to come.

Packing and Shipping:

Product Packaging:

• The piston pneumatic cylinder will be securely packed in a sturdy cardboard box.
• The box will have internal padding to prevent any damage during transit.
• The product will be accompanied by an instruction manual and any necessary mounting hardware.

Shipping:

• Shipping will be handled by a reputable courier service.
• Delivery times will vary depending on location.
• Customers will receive a tracking number once the product has been shipped.
• Please ensure that someone is available to receive the package at the delivery address.
