SMC Stainless Steel Joint KQG2T10-00 One Touch Fitting KQG2 Series 4E2-8FE/KQ2AA49
Product Attribute |
Attribute Value |
|---|---|
| Body Material | |
| Brand | |
| Connection Style | |
| Manufacturer Part Number | |
| Primary Type | |
| Series | |
| Standards | |
| Tube Size | |
| Type |
Product Description:
The SMC KQG2T series is a T-shaped (three-way) quick connector made of SUS316 stainless steel , designed specifically for pneumatic and fluid piping systems that require diversion or convergence.
It is suitable for a variety of harsh environments and media due to its compact structure, excellent corrosion resistance, and wide operating temperature range.
SUS316 stainless steel is used, which has better corrosion resistance compared to common SUS304 stainless steel, especially able to resist pitting and crevice corrosion caused by chlorides, and is suitable for chemical environments or fields with high hygiene requirements.
Sealing material: Use special fluororubber (FKM) with fluorine coating. This sealing combination provides excellent sealing performance and durability.
Applications:
The KQG2T series connectors are frequently employed in various scenarios due to their unique characteristics:
1. Pneumatic piping systems that necessitate diversion/convergence.
2. Equipment and pipelines used for dealing with corrosive fluids.
3. Industries like food and medicine that have strict hygiene standards (as they do not contain lubricating grease and conform to relevant hygiene regulations).
4. Processes involving the use of steam as a medium or requiring cleaning and disinfection.
5. Situations where different types of plastic hoses, such as nylon, polyurethane, FEP, PFA, etc., are utilized.
| Type | [Fitting] One-Touch Coupling | Fitting Type | Union with same diameter |
|---|---|---|---|
| Tube Size 1(φ) | 10 | Body Material | 316 Stainless Steel |
| Application | Standard | Thread Portion Material | No Thread Part |
| Seal/O-Ring Material | [Fluororubber] Special FKM (Fluorine Coated) | Tube to Tube Union Shape | [Union Tees] Union Tees |
| Compatible Fluid | Water / Air | Type Of Connection | Tube Connection |
Support and Services:
The Pneumatic Tee Fitting product comes with comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction. Our support team is dedicated to assisting with any technical queries, troubleshooting issues, and providing guidance on installation and maintenance.
Packing and Shipping:
Product Packaging and Shipping for Pneumatic Tee Fitting:
This Pneumatic Tee Fitting is carefully packaged to ensure its safe delivery to you. It is placed in a sturdy cardboard box with protective padding to prevent any damage during transit.
Shipping Information:
- Shipping method: Standard shipping
- Estimated delivery time: 3-5 business days
- Shipping cost: $5.99
