1050 Aluminum Coil Tubing For Superior Weldability And Conductivity
While not possessing the structural and strength properties of seamless aluminum tubes, this material excels in terms of cost reduction due to its heightened production efficiency and comparably straightforward manufacturing process. Additionally, it boasts remarkable processing flexibility, with its longitudinal (extrusion direction) mechanical properties significantly surpassing those of similar products.
Applications:
Large peak cooler
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
Industrial pure aluminum are characterized by high plasticity, corrosion resistance, good electrical and thermal conductivity, but low strength, can not be strengthened by heat treatment, cuttability is not good; can accept contact welding . Gas welding.
| 1- Appearance | Aluminium tubes without defect, without blow on its surface, without scratches, without pollution like grease or oil. |
| 2- Alloy Grade | 1050 |
|
3- Composition of alloy (%) Fe Mg Mn Ti Al Autres (others) |
0.40 0.05 0.05 0.05 99.50 0.05
|
|
Model Name |
Model Number |
Outside Diameter /mm |
Wall Thickness/mm |
Maximum Length/m |
Length/mm | Tensile Strength /MPa |
Non- proportional Elongation Strength /MPa |
Elongation After Break A50/mm |
| Main Size |
Series 1, Series 3 |
20-32 | 0.8-2.0 | 5000-15000 | ||||
| Example | 1050A | 28 | 1.0 | 18 | 7969 |
100~135
|
≥80 | ≥5.00 |
| 25 | 0.9 | 6959 | ||||||
| 23 | 1.5 | 9365 | ||||||
| 32 | 1.3 | 12266 |
Main Product:
How to order:
You can then download a form from this website and fill it out with basic details.
Send it to the provided e-mail address, and our engineers will price you based on the technical specifications.
http://mao.ecer.com/test/al-tubes.com/cases/how-to-order-15643.html
Alternatively, you can download the Technical Data Requirements Sheet directly.
Yuneng Product Requirements Table.docx
