3003 Aluminum Alloy Pipe H14 Corrosion-resistant Silver Outside Diameter 9.55mm
Brand 3003 Aluminum Alloy Pipe H14 Corrosion-resistant Silver Outside Diameter 9.55mm
Our sturdy, rust-free 3003H14 Aluminum Tube Pancake Coil features a satisfying 1.0%-to-1.5% manganese content that ensures superior performance. It's excellent malleability expands its adaptability for varied industries.
Its impressive resistance to corrosion is vital for heat exchangers in cooling and AC systems, greatly boosting efficiency. Plus, its exceptional welding properties ease assembly by amplifying product stability and reliability.
With dimensions of 9.35 mm diameter and a wall thickness of 0.38 mm, this swiss army knife of metal is popularly used in air conditioners, refrigerators, and automotive aircons.
To sum up, the 3003H14 aluminum tube pancake coil, emphasizing its exceptional performance and versatility, is now revered as a crucial part of modern refrigeration & AC hardware. This robust tube offers customers an unbeatable solution that's reliable, efficient, and long lasting for their modern machinery.
Features:
With our efficient machine for making 3003 round tubes, you can take comfort in knowing that each step is meticulously checked for top-notch quality. Our tube boasts superior corrosion resistance - it's both strong and supple. The blend of pure materials and careful annealing give it wonderfully robust properties after cold working.
The polished mirror finish on the aluminum makes it resistant to harmful chemicals, ensuring smooth operations. Plus, the uniform aluminum foil core provides dependable sealing against moisture and aromas, perfect for high-pressure conditions.
And did we mention its high heat tolerance? In other words, this 3003 cylindrical tube promises long-lasting durability in extreme temperature environments. With cold working reinforcement, its performance stays consistent across different high-temperature scenarios.
Assembly? It’s simple! Their lightness and flexibility allow them to be easily shaped and connected. Safety isn't compromised though; their supreme sturdiness guarantees efficiency.
Production Process:
Coil pipe
Raw material procurement-inspection-cleaning-extrusion-coiling-heat treatment-flaw detection -forming-inspection-finished product packaging
Stright pipe
Raw material procurement-inspection-cleaning-extrusion-coiling-straightening-flaw detection-fine cutting-cleaning-heat treatment-inspection-finished product packaging
echical Parameters:
Heat Exchanger Aluminum Tube
The main production specifications are listed as follows:
| Model Number | State | Wall Thickness mm | Tensile Strength MPa | Non-proportional Elongation Strength MPa | Elongation After Break A50mm |
| 1050 1060 1070 1050A | O | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 | |
| 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 |
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 | |
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 | |
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 |
Specifications can be customized according to customer requirements.
Applications:
Condensator
Evaporimeter
Air-conditioning
Icebox
Home freezer
Industrial freezer
Cold storage with cold exhaust pipe
Small warm wind
Lipstick shell
Eyebrow pen shell
Air conditioning connection pipe
Car water tank connecting pipe
Car air-conditioning connection pipe
Microchannel heat exchanger connecting tube
etc.
