China Low Noise Chemical Fume Hood PP Fume Hoods - Voltage 220V White Color for sale

Low Noise Chemical Fume Hood PP Fume Hoods - Voltage 220V White Color

Name: Low Noise Chemical Fume Hood PP Fume Hoods - Voltage 220V White Color
Brand: JIANGXI HUAZHIJUN TECHNOLOGY CO., LTD

Price Negotiable

Price: Negociation

MOQ: 1 STE

Delivery Time: 15 Days

Brand: SUCLAB

Product Description

Low Noise Chemical Fume Hood PP Fume Hoods - Voltage 220V White Color

Product Description:

PP Fume Hoods offer advanced protection against hazardous fumes and vapors. They are designed to provide users with a safe and effective working environment when dealing with hazardous chemicals. Chemical Fume Hoods are equipped with a Microcomputer Control System, which enables precise control and easy operation. The voltage of the Chemical Fume Hood is 220V, and the structure is horizontal, allowing for a wide range of applications. The size of the Chemical Fume Hood is highly customizable, making it suitable for various working areas. With a power of 50W, the Chemical Fume Hood is designed to be energy-efficient and reliable. It is ideal for providing users with a safe and secure environment during chemical processing.

Features:

Technical Parameters:

Parameter	Value
Product Name	PP Fume Hoods
Material	Stainless Steel
Structure	Horizontal
Airflow	400m³/h
Power	50W
Noise	≤60dB
Warranty	1 Year
Control System	Microcomputer
Installation Type	Wall Mounted
Lighting	LED

Material Description:
1. Upper cabinet:
The mainframe is made of porcelain white PP (polypropylene) sheet, welded by the same color and homogeneous welding rod. Excellent acid and alkali resistance, and excellent weather resistance. The top adopts a top-shield suction design, and the deflector is made of homogeneous PP material, which has excellent acid and alkali resistance. The installation size is scientific and reasonable, and there is no airflow dead angle, and the maximum exhaust gas capture performance can be obtained.
2. Operation surface:
The ventilated countertop adopts an integral welding design with the upper cabinet body. The human operating surface is equipped with water-retaining and anti-overflow treatment. The countertop can also be equipped with other material countertops according to customer requirements; the upper sink is configured according to user requirements.
3. Lower cabinet:
The body of the storage cabinet is made of porcelain white PP (polypropylene) sheet, and the column is formed into a “square tube structure” and a “T”-shaped structure through the bending process, which can obtain a good load-bearing capacity.
4. Moving door: stepless design, light feel
a. Operating window: It is made of 5mm tempered glass with excellent acid and alkali resistance.
b. Adjustable door frame: gray PP c-shaped groove, embedded combination to ensure safety and durability.
c. Adjustable door suspension steel cable: each fume hood adjusts the door steel cable connection.
d. Adjusting door balance weight: adopt PP material weight box design.
5. Circuit equipment:
a. Switch: The integrated control panel with liquid crystal display function is used to visually control various parameters, including fan switch, lighting switch, and main power switch.
b. Socket part: Each fume hood is equipped with two 220V10A power sockets with a splash cover.
6. Other accessories:
Door handle: acid and alkali resistant PP material (color options: azure blue, magnetic white, light gray, dark gray)
Door hinge: acid and alkali resistant PP material (color options: azure blue, magnetic white, light gray, dark gray)
Air collecting hood: acid and alkali resistant PP material, standard 250MM air outlet (the air outlet size can be customized according to requirements)
Diversion clamp: acid and alkali resistant PP material (color options: azure blue, light gray, black)
Pulley: PP silent pulley, low friction, wear-resistant, and corrosion-resistant.

Specifications

Model	FMH-P1200	FMH-P1500	FMH-P1800
External Dimension(WDH)	12008502350mm	15008502350mm	18008502350mm
Working Zone Size(WDH)	9766531100mm	12766531100mm	15766531100mm
Maximum opening of sliding door	820mm(Standard vertical adjustable door)
The exhaust volume when the regulating door is fully open and the surface wind speed is 0.5m/s(about)	23.4CMM/840CFM	30.6CMM/1100CFM	50.8CMM/1825CFM
Tabletop material	It is made of porcelain white PP (polypropylene) sheet with a thickness of 8MM, bends and thickens and overflows. Optional solid core physical and chemical board countertops, epoxy resin countertops or ceramic countertops, etc.
Operation window	Transparent tempered glass, thickness: 5MM
Gas hood	Adopt cone-shaped necking air collecting hood
lighting device	Full cover fluorescent lamp 30Wx1	30Wx1	40Wx1
Power outlet	AC220V/10A 4 outlets
Circuit board	One fluorescent lamp, one LCD panel switch and one master control circuit board
Optional configuration: Small water cup,water tap,water tank,water valve,water nozzle
