10G SFP+ To 10G SFP+ AOC Ethernet Cable Rack Connection Infiniband QDR / DDR / SDR

Price Negotiable

Price: Negotiable

MOQ: 10

Delivery Time: 10 days

Brand: Coloroptic

Product Description

AOC Cable 10G SFP+ To 10G SFP+ In-Rack Connection Infiniband QDR/DDR/SDR

General Description

The SFP+ active optic cables are a high performance, low power consumption, short range interconnect solution supporting InfiniBand QDR/DDR/SDR,12.5G/10G/8G/4G/2G fiber channel, PCIe and SAS. It is compliant with the SFP+ MSA and IEEE P802.3ba. SFP+ AOC is one kind of parallel transceiver which provides increased port density and total system cost savings.

Product Details

Absolute Maximum Ratings
Parameter	Symbol	Min	Max	Unit
Storage Temperature	Ts	-40	+85	°C
Operating Humidity	RH	0	85	%
Supply Voltage	Vcc	-0.5	3.6	V

Recommended Operating Conditions
Parameter	Symbol	Min	Typical	Max	Unit
Operating Case Temperature	Tc	0		+70	°C
Supply Voltage	Vcc	3.14	3.3	3.46	V
Supply Current	Icc			250	mA
Bit Rate	BR		10.3125	11.3	Gbps

Electrical Characteristics
Parameter	Symbol	Min	Typical	Max	Unit	Notes
Transmitter Characteristics
Input differential impedance	Rin		100		Ω	1
Differential data input swing	Vin,pp	180		700	mV
Transmit Disable Voltage	VD	2		Vcc	V
Transmit Enable Voltage	VEN	Vee		Vee+0.8	V
Receiver Characteristics
Differential data output swing	Vout,pp	300		850	mV	2,5
Data output rise time, fall time	tr	28			ps	3
LOS Fault	V_LOS _fault	2		Vcc_HOST		4
LOS Normal	V_{LOS norm}	Vee		Vee+0.8		4
