0805 SMD LED 385nm 2012 size 405nm UV Emitting diode for anti-mosquito lamp
Price:
Negotiable
MOQ:
10,000pcs
Delivery Time:
5-15 days
Brand:
BOSMFC
Product Description
0805 SMD LED 385nm 2012 Size 405nm UV Emitting Diode for Anti-Mosquito Lamp
High-performance UV emitting diode specifically designed for anti-mosquito lamp applications, featuring excellent reliability and energy efficiency.
Key Features
- Pure gold wires bonding for superior connectivity
- Long life span of 50,000 hours
- Pb-free and radiation-free construction
- Low-temperature & lead-free reflow soldering compatible
- Efficient heat dissipation design
- Energy-saving and environmentally friendly
Technical Specifications
| Parameter | Symbol | Color | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|---|
| Dominant Wavelength | λd | UV | 380 | --- | 390 | nm | IF=20mA |
| Power dissipation | Pt | UV | --- | 315 | --- | mW | IF=20mA |
| Forward voltage | VF | UV | 2.8 | --- | 3.6 | V | IF=20mA |
| Viewing angle | --- | 120 | --- | deg | IF=20mA | ||
| Reverse current | IR | --- | --- | 5 | uA | IF=20mA | |
| Operation Temperature | -40~+85℃ | ||||||
| Size | 2.0×1.2×1.1mm | ||||||
| Storage Temperature | -40~+100℃ | ||||||
| Packing | 3000pcs/reel | ||||||
Applications
- Medical equipment and lighting indication
- LED backlighting and SMD type indicator
- Mobile phone and mobile power supply
- Decoration light, backlight in dashboards and switches
- GPS navigation equipment
- Computer keyboard/switch indicator, flat backlight for LCD, switch and symbol
Materials
Company Information
Dongguan Lanjin Optoelectronics Co., Ltd., established in 2005, is a professional manufacturer specializing in light emitting diodes, LED digital displays, SMD LEDs, through-hole LEDs, and LED PCB assembly services. Our 2,500 square meter factory features modern purification constant temperature and humidity anti-static production workshops. We have passed ISO9001:2015 international Quality Management System certification and are currently applying for ISO14001 Environmental Management System certification. With 18 years of development, we have achieved 2 national invention patents, 12 practical new-type patents, and 2 software invention patents. All products comply with EU RoHS standards. Lanjin has absorbed advanced manufacturing technology from Japan, Korea, and Western Europe. With high starting point and quality market positioning, we have developed high temperature resistance & long life LEDs widely used in communication equipment, switching power supplies, decorative lighting, multi-speakers, DVD, and other electronics. Lanjin always adheres to the principle of "Quality and customer first," providing customized services according to customer demands. LED lights the world, Lanjin lights your life!
Packing and Shipping
Inner packaging: Anti-static Bag Vacuo Packaging
Outer packaging: Standard export carton packing
Outer packaging: Standard export carton packing
Frequently Asked Questions
Q1. Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. Free samples will be available. We can also make samples according to your requirements.
Q2: What's the delivery time?
A: It usually takes about 5-7 days to produce an order. The exact delivery time may vary depending on the order and current production schedule.
Q3: What's your warranty terms?
A: The warranty for all our LED products is 2 years.
Q4: How does your factory do regarding quality control?
A: Quality is our priority. We believe quality is our marketing advantage and attach great importance to quality control from the beginning to the end of production. Every product is fully assembled and carefully tested before being packed for shipment.
