Metal Sheet / Aluminium Fiber Laser Marking Machine 20W 30W 50W
Price:
USD3500 - USD4500 / Set
MOQ:
1
Delivery Time:
15 - 30 work days
Brand:
CKD
Product Description
Enclosed Laser Marking Machine Safty 20W 30W 50W For Metal Sheet And Aluminium
APPLICATION INDUSTRIES
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, etc.
PRODUCT PARAMETER
| Laser Type | Fiber Laser |
| Laser Power | 20W / 30W / 50W |
| Cooling Mode | Air Cooling |
| Graphic Format Supported | AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP |
| Working Accuracy | 0.01mm |
| Laser Source Brand | MAX |
| Weight (KG) | 55 KG |
| Marking Area | 110mm*110mm |
| Control Software | EZCAD |
| Marking Depth | 0.01- 2 mm |
| Marking material | Metal Sheet / steel / stainless |
PRODUCT DESCREPTION
The differences between optical fiber, carbon dioxide and ultraviolet laser marking machines
1, the laser is different: fiber laser marking machine uses fiber laser, carbon dioxide laser marking machine uses CO2 gas laser, ultraviolet laser marking machine uses short-wavelength ultraviolet laser.
Ultraviolet laser is a very different technology from carbon dioxide and fiber laser technology, ultraviolet laser is also known as blue laser beam, the technology has a low heat engraving ability, it does not heat the surface of the material like fiber and carbon dioxide laser marking machine, belongs to cold light engraving.
2, the laser wavelength is different: the laser wavelength of the fiber marking machine is 1064nm, the laser wavelength of the carbon dioxide laser marking machine is 10.64μm, and the laser wavelength of the ultraviolet laser marking machine is 355nm.
3. Different application fields: CO2 laser marking machine is suitable for most non-metallic materials and some metal products engraving, fiber laser marking machine is suitable for most metal materials and some non-metallic materials engraving, UV laser marking machine can clearly mark all plastic and other materials that have adverse reactions to heat, Especially suitable for food, pharmaceutical packaging materials marking, punching microholes, high-speed division of glass materials and complex graphics cutting of silicon wafers and other applications.
SAMPLES
PACKAGE AND SHIPMENT
1.We have three layers package. For the outside, we adopt wood craft case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by thickening plastic bag for waterproof.
2.Air-worthy packing or Sea packing which with international standard.
Our Service
1.Pre-Sales Service
Inquiry and consulting support.
Sample testing support.
View our Factory.
2.After-Sales Service
Training how to instal the machine, training how to use the machine.
Engineers available to service machinery overseas.
We provide two-year machine warranty. In case it exists machine problem, we will solve the problem through email, skype, phone or video. If the problem still exists, we will send our technician to customer's plan for machine repair. We will respond to customer's question as soon as possible.
COOPERATION COMPANY
FAQ
Q1. What support do I get with my laser machine?
A1: All of our machines come with unlimited, lifetime support.
Q2, What do I need to get started with a the laser?
A3: The space for the machine to stand, a computer for your laser machine to run off, the sockets for the laser equipment to connect to, and yourself for the training
Q3. How can I get machine's spare parts?
A5:There are two methods. Spare parts can be ordered together with the machine.
