X-28 Van Refrigeration System with Direct Engine Drive R404a Refrigerant and Parallel Flow Condenser for Long-Distance Transport
Price:
negotiation
MOQ:
1PCS
Delivery Time:
20
Brand:
YINHUASHENG
Product Description
X-28 Van Refrigeration System (Top-mounted)
Product Overview
The X-28 is a direct engine-driven refrigeration system designed for 40m³ refrigerated trucks. This top-mounted unit provides reliable temperature control for transporting chilled and frozen goods across long distances.
- Direct engine drive system
- Ideal for 40m³ refrigerated trucks
- Suitable for chilled & frozen foods, medical supplies, fruits, vegetables, ice cubes, and seafood
- OEM customization services available
- Low operational and service costs
- Easy installation process
- Optimized for long-distance transportation
Key Features
- Eco-friendly refrigerant R404A (R134a system also available)
- Corrosion-resistant, high-strength FRP canning material
- Aluminum fin parallel flow condenser - lightweight, compact, with excellent heat exchange performance
- Inner grooved copper tube with powerful evaporator - large airflow with superior coil protection
- Strong, reliable compressor specifically designed for R404a systems
- Digital display control panel with minimal operation steps
- HP (High Pressure) and LP (Low Pressure) switch safety protection
- Large cooling capacity and reliable overall performance
Technical Specifications
| Parameter | Specification |
|---|---|
| Unit Model | X28 |
| Applicable Temperature | -25℃ ~ +25℃ |
| Box Volume | ≤6m³ |
| Cooling Capacity | 2150 W @ 0℃ 1130 W @ -18℃ |
| Compressor | Model: 5H14 CC: 138 CC Lubricating Oil: PAG 68 |
| Evaporator | Material: Inner grooved copper tube Number of Fans: 1 PCS |
| Condenser | Material: Parallel flow condenser Number of Fans: 1 PCS |
| Refrigerant | R404a |
| Refrigerant Charge | 0.8KG |
| Box Temperature Adjustment | Electronic digital display |
| Safety Protection | High and low pressure switch |
| Defrosting | Hot gas defrost automatically |
| Weight/Dimensions | Evaporator Weight: 13 KG Condenser Weight: 21 KG Evaporator Dimensions: 780×580×210 (mm) Condenser Dimensions: 960×690×250 (mm) |
| Drive Model | Non-independent engine driven |
