HUASHENGTHERMO HT-480 Non-independent Engine Driven Refrigeration Unit with R404a Refrigerant and Parallel Flow Condenser Featuring Electronic Digital Display
The HUASHENGTHERMO HT-480 is a robust, non-independent engine driven refrigeration unit designed for reliable temperature control in transport applications, maintaining precise temperatures from -25℃ to +25℃.
- Eco-friendly refrigerant R404A (R134a system also available)
- Corrosion-resistant, high-strength FRP canning material for durability
- Aluminium fin parallel flow condenser for efficient heat exchange
- Inner grooved copper tube evaporator with large airflow capacity
- Specialized R404a compressor for consistent refrigeration performance
- Digital display control panel for intuitive temperature monitoring
- HP and LP switch safety protection for operational safety
- Large cooling capacity with reliable overall performance
| Parameter Category | Specification |
|---|---|
| Unit Model | HT-480 |
| Applicable Temperature | -25℃ ~ +25℃ |
| Box Volume | ≤18m³ |
| Cooling Capacity | 0℃: 4750 W -18℃: 2130 W |
| Compressor | Model: 5H14 CC: 135 CC Lubricating Oil: PAG 68 |
| Evaporator | Material: Inner grooved copper tube Number of Fans: 2 PCS |
| Condenser | Material: Parallel flow condenser Number of Fans: 2 PCS |
| Refrigerant | R404a (Refrigerant Charge: 1.4KG) |
| Box Temperature Adjustment | Electronic digital display |
| Safety Protection | High and low pressure switch |
| Defrosting | Hot gas defrost automatically |
| Weight | Evaporator: 26 KG Condenser: 35 KG |
| Dimensions | Evaporator: 1010*640*250 Condenser: 1170*520*415 |
| Drive Model | Non-independent engine driven |
The applicable compartment volume is for reference only, and actual performance depends on compartment volume, insulation performance, environmental temperature, and transported goods.
The compressor operates at 2000 rpm, with 12V/24V voltage selection available according to requirements.
- Technological Leadership: Advanced technology and skilled team for highest standards in design and manufacturing
- Customization Capabilities: Tailored solutions for size, capacity, temperature range, and special requirements
- Quality Assurance: Strict quality control with premium materials and rigorous testing
- Customer Service: Comprehensive support including technical assistance and after-sales service
- Energy Efficiency: Advanced energy-saving technologies to reduce operating costs and environmental impact
High-definition product images, installation diagrams and on-site application photos are available upon request. Please contact us to obtain detailed visual materials of the HT-480 refrigeration unit.
