2430 Mirco Brushless DC Gear Motor Dia 24mm Low Noise Long Life Time
Dia 24mm mirco dc brushless gear motor planetary gearbox 2430 brushless motor low noise long life time
Motor Type: DC Brushless planetary gear motor
Item NO. DPG24-2430
Voltage 6V~24V
Speed 15~500RPM
Working Current 5A Max
Body Diameter:24MM
Feature:
A. High power range from 5W to 100W
B. Rich stock and fast shipping time in 10 working days
C. Easy for speed & direction adjustment
D. 10mm to 45mm size range with low noisy
E. Strong stability for driver/controller
F. Lifetime above continuous 10000 hours
G. IP65 protection rank is available for us
H. Above 80% enery efficiency motor is available
I. 3D file is available if customers needed
J. Permanent magnet brushless dc motor
K.High-performance and stable matching driver and controller
Specification:
| Item | Dc brushless gear motor DPG24-2430 |
| Size | Diameter24mm |
| Working Voltage | 6V~12V |
| Speed | 15~300RPM |
| Shaft diameter | 4mm |
| Working Current | 85mA Max |
| Typical Current | 62mA |
| Shaft length | Customized |
| Fall time | 50ms Max |
| Lifetime | 10000hours constant run |
| Certificate | CE,ROSH |
Typical Specification:
Note:Motor's voltage,speed,wire length,connector type can be customized
Typical application
Our products widely used in Robot, 3D pen and machine, Power Lock ,Electronic Lock ,Optic equipment ,Micro Mechanism, money detcotor, printer ,pump etc.
FAQ
Q: How to order?
A: send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit → mass production →
cargo ready → balance/delivery → further cooperation
Q: How about Sample order?
A: Sample is available for you. please contact us for details. Once we charge you sample fee, please feel easy, it would be refund
when you place formal order.
Q: Which shipping way is available?
A: DHL, UPS, FedEx, TNT, EMS, China Post,Sea are available.The other shipping ways are also available, please contact us if you
need ship by the other shipping way.
Q: How long is the deliver[Producing] and shipping?
A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.
Q: My package has missing products. What can I do?
A: Please contact our support team and we will confirm your order with the package contents.We apologize for any inconveniences.
Q: How to confirm the payment?
A: We accept payment by T/T, PayPal, the other payment ways also could be accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.
