12mm High Speed DC Gear Motor 5V N20 12V Micro DC Geared Motor For Robots
12mm dc gear motor GM12-N20 high speed 5v n20 12v micro motor dc geared motor used in robots
Motor Type: DC Brush motor
Item NO. N20 motor
Voltage 1.5V~24V
Speed 3000~35000RPM
Working Current 1A Max
Body Diameter:12MM
reduction ratio:5-1000:1
1 Year Warranty
Description:
Voltage:DC Input 1.5V,3v,4.5v, 5v,6v,7.2v,9v,12v (Can be Customized)
Power:(Can be Customized)
Speed:Variable speed from 0.5-3000rpm (Can be Customized)
Torque:Up to 2kgf.cm rated torque(Can be Customized)
Shaft:shaft Dia: 3mm ,Shaft type: Bare /D-Cut /Double D-Cut /Pin Hole /Keyway shaft (Can be Customized)
Specification:
| Item | Dc brush gear motor DGA12-N20 |
| Size | Diameter12mm |
| Working Voltage | 1.5V~24V |
| Speed | 15~1000RPM |
| Torque | 0.1-3kg.cm |
| Working Current | 55mA Max |
| Typical Current | 62mA |
| Lifetime | 500hours constant run |
| Certificate | CE,ROHS |
Typical Specification:
Note:Motor's voltage,speed,wire length,connector type can be customized
Typical application
Our products widely used in Robot, 3D pen and machine, Power Lock ,Electronic Lock ,Optic equipment ,Micro Mechanism, money detcotor, printer ,pump etc.
