12 Female Pins MIL-DTL-26482 Series 1 Electroless Nickel Plating Mil Dtl 26482 I.MS3112E14-12SNL
Miniature Connector MIL-DTL-26482 Series Ⅰ Type ,MS3112E14-12SNL.12 Female Pins.Electroless Nickel Plating.
Part Number:MS3112E14-12SNL
Product Description:
MIL-DTL-26482 Series I is a box mounting receptacle designed for applications. This MIL-DTL-26482 Series I receptacle is a miniature connector with a 7.5A current rating. The shell material is an aluminum alloy and it is finished with an electroless nickel plating. This product offers excellent corrosion resistance and durability in the most demanding environments.
Features:
- Product Name: MIL-DTL-26482 Series Ⅰ
- Shell Finish: Electroless Nickel
- Connector Type: Miniature Connector
- Number of Contacts: 12
- Contact Termination: Crimp
- Current Rating: 7.5 A
Technical Parameters:
| Product Name | Technical Attributes |
|---|---|
| MIL-DTL-26482 Series Ⅰ | Connector Type: Miniature Connector Gender: Receptacle Number of Contacts: 12 Coupling Nut Material: Aluminum Alloy Shell Size: 14 Shell Finish: Electroless Nickel Contact Termination: Crimp Current Rating: 7.5 A Voltage Rating: 500V |
Product Pictures
Applications:
KAIDA MS3112E14-12SNL Receptacle Connector, which complies with MIL-DTL-26482 Series Ⅰ standard, is designed as an ideal solution for the applications and scenarios that require high-performance electrical connections with voltage up to 500V. This MIL-DTL-26482 Series Ⅰ Receptacle Connector is made of durable aluminum alloy material and features 12 contacts and 14 shell size. It is a reliable and cost-effective choice for many applications, especially for the applications and scenarios that require a MIL-DTL-26482 Series Ⅰ Receptacle Connector with voltage up to 500V.
Customization:
KAIDA MIL-DTL-26482 Series Ⅰ Connector with Electroless Nickel Plating is a reliable connection solution for 500V applications with 12 contacts and 7.5 A current rating. This connector features a 14 shell size and aluminum alloy coupling nut material, meeting MIL-DTL-26482 specifications. Model Number: MS3112E14-12SNL. Place of Origin: China.
Support and Services:
MIL-DTL-26482 Series Ⅰ products are supported by a team of dedicated service and technical support engineers. Our engineers are available to provide assistance with product design, installation, testing, troubleshooting, upgrades, and more.
We provide product-specific support and service for the entire MIL-DTL-26482 Series Ⅰ product line. Our team is prepared to help you with installation, system setup, software support, and more. We offer both on-site and remote support, as well as telephone and email assistance.
If you need assistance with a MIL-DTL-26482 Series Ⅰ product, please contact us for professional technical support and service.
Packing and Shipping:
MIL-DTL-26482 Series I Packaging and Shipping:
The MIL-DTL-26482 Series I connectors should be stored in their original packaging in a dry environment. They should be stored and shipped in antistatic bags or other approved package designs. The containers should be labeled with product part numbers, lot numbers, and revision levels. During shipping, the connectors should be securely packaged in appropriate containers with adequate cushioning materials to prevent damage during transit.
